KEMET T521D226M050ATE090 Polymer Tantalum Capacitor
The T521D226M050ATE090 is a high-performance polymer tantalum SMD capacitor offering 22 uF capacitance, 20% tolerance, and a 50 VDC rating. It features low ESR, non-combustible construction, and a molded design suitable for demanding electronic applications. With a maximum height of 3.1mm and dimensions of approximately 7.3mm in length, it provides excellent reliability, high voltage endurance, and temperature stability from -55°C to +125°C. This component is RoHS compliant and designed for space-constrained environments requiring durable, low-ESR capacitors.
KEMET T521D226M050ATE090 Polymer Tantalum Capacitor Specifications:
- Capacitance: 22 uF
- Capacitance Tolerance: 20%
- Voltage DC: 50 VDC
- Dimensions: Length 7.3mm +/-0.3mm, Height Max 3.1mm
- Operating Temperature Range: -55°C to +125°C
- Dissipation Factor: 10% at 120Hz 25°C
- Resistance: 90 mOhms at 100kHz 25°C
- Ripple Current: 1870 mA at 85°C
- Leakage Current: 110 uA at 25°C
- Shelf Life: 52 Weeks
- Packaging: T&R, 500 pcs, 178mm reel
- RoHS Compliant: Yes
- Termination: Tin
- Life Expectancy: 2000 hours at 125°C
Buy the KEMET Series T-Series T521D226M050ATE090: 22uF 50VDC Polymer Tantalum Capacitor
Discover the KEMET Series T521D226M050ATE090 polymer tantalum capacitor, offering 22 uF capacity, 50 VDC rating, and low ESR for optimal electronic performance. Its molded design ensures durability, high reliability, and stable operation across a wide temperature range from -55°C to +125°C. Suitable for space-constrained applications, it features RoHS compliance and robust tin terminations. Order online now and enhance your electronic assemblies with this high-quality, low ESR capacitor that guarantees dependable performance and long-term stability in demanding environments.
Order your KEMET Series T521D226M050ATE090 today and equip your projects with a reliable high-voltage polymer tantalum capacitor designed for durability and stability.
Frequently Asked Questions
Where can I buy KEMET T521D226M050ATE090?
You can click on the BUY or RFQ button to purchase T521D226M050ATE090 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T521D226M050ATE090?
You can download the T521D226M050ATE090 datasheet or visit the KEMET website for support.
Who is the manufacturer of T521D226M050ATE090?
KEMET
