KEMET T521D565M050ATE070 Polymer Tantalum Capacitor
This is a polymer tantalum SMD capacitor with a capacitance of 5.6 microfarads, a voltage rating of 50 VDC, and a tolerance of 20%. Featuring low ESR, high voltage capability, and a molded construction, it provides reliable performance in surface-mount applications. The device has a low resistance of 70 mOhms at 100kHz and is non-combustible, making it suitable for high-reliability circuits. Dimensions include a length of 7.3mm, height up to 3.1mm, and a footprint of 7343. It is RoHS compliant, with a life span of 2000 hours at 125°C, and offers excellent electrical parameters for demanding electronic designs.
KEMET T521D565M050ATE070 Polymer Tantalum Capacitor Specifications:
- Capacitance: 5.6 uF
- Capacitance Tolerance: 20%
- Voltage Rating: 50 VDC
- Dimensions: Length 7.3mm +/-0.3mm, Height Max 3.1mm
- Footprint: 7343
- Temperature Range: -55 to +125°C
- Rated Temperature: 105°C
- Life: 2000 hours at 125°C
- Dissipation Factor: 10% at 120Hz, 25°C
- Equivalent Series Resistance: 70 mOhms (100kHz, 25°C)
- Leakage Current: 28 μA at 25°C
- RoHS Compliant: Yes
- Termination: Tin
- Packaging: T&R, 178mm reel, quantity 500
- RoHS: Yes
- Material: Polymer Tantalum, Molded
- Features: Low ESR, Non-Combustible, High Voltage
- Operating Temperature Range: -55°C to +125°C
- Applicable for high-reliability applications, low impedance circuits, and surface-mount device requirements
Buy the Buy KEMET Polymer Tantalum Part Number T521D565M050ATE070 Online
Secure your supply of high-performance Polymer Tantalum Capacitors by purchasing KEMET T521D565M050ATE070 online today. Designed for demanding electronic circuits, this 5.6 microfarad, 50VDC rated surface-mount component features low ESR and non-combustible construction for enhanced safety and durability. With a compact form factor of 7.3mm by 3.1mm, it ensures reliable operation across a wide temperature range from -55°C to 125°C. Perfect for high-voltage and low-impedance applications, order now to improve your circuit’s stability and longevity.
Buy KEMET T521D565M050ATE070 now and experience unmatched reliability and performance with high voltage and low ESR polymer tantalum capacitor.
Frequently Asked Questions
Where can I buy KEMET T521D565M050ATE070?
You can click on the BUY or RFQ button to purchase T521D565M050ATE070 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T521D565M050ATE070?
You can download the T521D565M050ATE070 datasheet or visit the KEMET website for support.
Who is the manufacturer of T521D565M050ATE070?
KEMET
