KEMET T521X156M063ATE035 Polymer Tantalum Capacitor
This polymer tantalum chip capacitor offers a capacitance of 15 µF with 20% tolerance, rated at 63 VDC, ideal for high-reliability applications requiring low ESR and non-combustibility. Its SMD, molded design ensures compactness and ease of placement, with a height maximum of 4.3mm. Suitable for space-constrained circuits, it features RoHS compliance, low impedance, and high voltage handling, making it suitable for automotive, industrial, and consumer electronics requiring stable performance over temperature ranges from -55°C to +125°C. It also maintains long shelf life and reliable operation under demanding conditions.
KEMET T521X156M063ATE035 Polymer Tantalum Capacitor Specifications:
- Capacitance: 15 µF
- Capacitance Tolerance: 20%
- Rated Voltage: 63 VDC
- Maximum Height: 4.3mm
- Dimensions: Length 7.3mm ±0.3mm, Width 3.6mm ±0.1mm, Lead Pitch 2.4mm ±0.1mm
- Temperature Range: -55°C to +125°C
- Dissipation Factor: 10% at 120Hz 25°C
- Equivalent Series Resistance: 35 mOhms at 100kHz 25°C
- Ripple Current: 3380 mA rms at 85°C
- Leakage Current: 94.5 µA for 5 min at 25°C
- Life Expectancy: 2000 hours at 125°C
- Packaging: T&R, 178mm reel, 500 units
- RoHS compliant: Yes
- Construction: Molded Polymer Tantalum, SMD
- Certifications: RoHS
Buy the KEMET T521X156M063ATE035 – Reliable Polymer Tantalum Capacitor for Industrial Applications
Purchase the high-quality Polymer Tantalum Capacitor from KEMET online today. Designed for reliability and low ESR, this 15 microfarad, 63-volt component is perfect for demanding industrial and automotive applications. Its SMD, molded form ensures easy installation, while RoHS compliance guarantees environmental safety. With a maximum height of just 4.3mm, it fits in tight spaces without compromising performance. Ensure your circuits operate smoothly under wide temperature ranges from -55°C to +125°C, with long shelf life and consistent durability. Buy now for fast delivery and high reliability.
Order your KEMET Series T521 capacitors today and give your projects the dependable quality they deserve, perfect for space-constrained and high-performance circuits.
Frequently Asked Questions
Where can I buy KEMET T521X156M063ATE035?
You can click on the BUY or RFQ button to purchase T521X156M063ATE035 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T521X156M063ATE035?
You can download the T521X156M063ATE035 datasheet or visit the KEMET website for support.
Who is the manufacturer of T521X156M063ATE035?
KEMET
