KEMET V11 Voltage Balancing Resistor
The product is a series of wire-wound resistors designed for voltage balancing and discharge of electrolytic capacitors. They fit capacitor diameters ranging from 50 to 90 mm and are made of stainless steel with ceramic cores, coated with high-temperature silicone for durability. Compliant with CECC 40201 and MIL-R26E standards, these resistors feature resistance values from 10 to 47 kΩ with a tolerance of ±5%. Rated at 700 VDC, they operate effectively within temperatures from -55°C to +105°C, with adjustable mounting brackets for easy installation.
KEMET V11 Voltage Balancing Resistor Specifications:
- Standards: CECC 40201, MIL-R26E
- Resistance range: 10-47 kΩ
- Resistance tolerance: ±5%
- Rated voltage: 700 VDC
- Temperature range: -55°C to +105°C
- Material: Stainless steel with ceramic core, high-temperature silicone coating
- Fits capacitor diameters: 50-90 mm
- Dimensions (PYR 5008): Length 22.0 mm, Width 40 mm, Height 10.6 mm, Weight approx 10 g
- Dimensions (PYR 7511): Length 32.0 mm, Width 50 mm, Height 10.6 mm, Weight approx 10 g
- Adjustable brackets: Up to A = 28.5 mm
Buy the Rifa Series PYR Voltage Balancing Resistor: V11
Experience high-performance voltage balancing and discharge solutions with Rifa PYR resistors, made from stainless steel and ceramic cores for durability. rated at 700 VDC and operating efficiently from -55°C to +105°C, these resistors are ideal for electrolytic capacitor applications. Their adjustable mounting brackets facilitate quick installation in various sizes, supporting capacitor diameters of 50-90 mm. Choose Rifa PYR resistors for reliable, long-lasting performance in demanding electronic and power systems, ensuring safety and stability in your applications.
Buy Rifa PYR series resistor V11 now and ensure reliable voltage balancing and capacitor discharge with easy mounting features.
Frequently Asked Questions
Where can I buy KEMET V11?
You can click on the BUY or RFQ button to purchase V11 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part V11?
You can download the V11 datasheet or visit the KEMET website for support.
Who is the manufacturer of V11?
KEMET
