KEYSTONE 4898 Fullrange Loudspeaker
The FR 10 HM 4 Ohm is a 10 cm full-range loudspeaker with a tweeter cone, designed for vehicle and mobile home applications. It features a moisturized cone and a robust metal basket, delivering a rated power of 20W and a maximum power of 30W. With a frequency response from 95 to 22,000 Hz, it offers clear sound reproduction. The speaker has a nominal impedance of 4 Ohms, a resonance frequency of 120 Hz, and a sound pressure level of 86 dB at 1 W/1 m. Its compact design and high efficiency make it ideal for demanding audio installations.
KEYSTONE 4898 Fullrange Loudspeaker Specifications:
- Rated Power: 20W
- Maximum Power: 30W
- Impedance: 4 Ohm
- Frequency Response: 95-22000 Hz
- Sound Pressure Level: 86 dB (1 W/1 m)
- Resonance Frequency: 120 Hz
- Voice Coil Diameter: 14mm
- Total Q Factor: 1.13
- Magnetic Induction: 117 mT
- Cutout Diameter: 94mm
- Weight: 0.34 kg
- Heat Resistance: -25°C to 70°C
- Magnetic Flux: 100 pWb
- Effective Piston Area: 50 cm²
- Force Factor: 217 m
- Mechanical Q Factor: 5.35
- Electrical Q Factor: 1.44
- D.C. Resistance: 3.2 Ohm
- Inductance of Voice Coil: 0.2 mH
Buy the Buy Visaton Fullrange Speaker Part Number 4898 Online
Enhance your audio experience with this high-performance 10 cm full-range loudspeaker. Providing a wide frequency response from 95 to 22,000 Hz, it features a moisture-resistant cone and robust metal basket, ideal for vehicle and mobile home applications. Its rated power of 20W and maximum 30W ensure clear, dynamic sound; with a nominal impedance of 4 Ohms, it seamlessly integrates into your existing audio system. Compact and durable, this speaker is perfect for demanding audio installations requiring reliability and excellent sound quality.
Order your Visaton Series4898 10 cm full-range speaker today and enjoy high-quality sound performance for your vehicle or mobile home projects.
Frequently Asked Questions
Where can I buy KEYSTONE 4898?
You can click on the BUY or RFQ button to purchase 4898 from an authorized KEYSTONE distributor.
How do I troubleshoot issues or seek technical support for part 4898?
You can download the 4898 datasheet or visit the KEYSTONE website for support.
Who is the manufacturer of 4898?
KEYSTONE
