KINGBRIGHT KCPSC04123 Green LED Display
The KCPSC04-123 is a surface-mount 7-segment display with a 0.4-inch character height, featuring a white diffused lens and green AlGaInP on GaAs LED technology. It offers high contrast, bright output, and operates efficiently with low current. The display is mechanically robust, categorized for luminous intensity, with a grey face and white segments. It has a common cathode configuration, right-hand decimal point, and complies with Level 2a moisture sensitivity standards, making it suitable for industrial, imaging, video, and vision applications.
KINGBRIGHT KCPSC04123 Green LED Display Specifications:
- Character height: 0.4 inch
- Package: 400 pieces per reel
- Luminous intensity: categorized
- Gray face, white segments
- Power dissipation: 75 mW
- DC Forward Current: 30 mA
- Peak Forward Current: 150 mA
- Reverse Voltage: 5 V
- Operating Temperature: -40°C to +85°C
- Wavelength: 574 nm peak, 570 nm dominant
- Spectral Line Half-width: 20 nm
- Forward Voltage: 2.4 – 2.5 V at 20 mA
- Capacitance: 15 pF
- Dimensions: 9.3 mm length, 5.75 mm width, internal circuit diagram available
- Moisture sensitivity level: 2a
- RoHS compliant
Buy the Kingbright Series Display: KCPSC04-123 Green 7-Segment Surface Mount
Order the Kingbright KCPSC04-123 green LED display online today to enhance your industrial, imaging, or video projects. This 0.4-inch surface-mount display features high contrast, low current operation, and robust construction. Its white diffused lens, categorized luminous intensity, and compliance with Level 2a moisture standards ensure reliability and clarity. Perfect for professional applications requiring bright, energy-efficient indicators, this display combines durability with superior performance, available now for swift delivery to meet demanding project timelines.
Buy Kingbright KCPSC04-123 now and experience unmatched reliability and performance with a durable 7-segment display designed for industrial and vision applications.
Frequently Asked Questions
Where can I buy KINGBRIGHT KCPSC04123?
You can click on the BUY or RFQ button to purchase KCPSC04123 from an authorized KINGBRIGHT distributor.
How do I troubleshoot issues or seek technical support for part KCPSC04123?
You can download the KCPSC04123 datasheet or visit the KINGBRIGHT website for support.
Who is the manufacturer of KCPSC04123?
KINGBRIGHT
