KINGBRIGHT KPT3216EC High Efficiency Red LED
The KPT-3216EC from Kingbright is a surface-mount, high-efficiency red rectangular chip LED measuring 3.2mm by 1.6mm with a thickness of 0.75mm. It features gallium arsenide phosphide on gallium phosphide, emitting orange-red light with a dominant wavelength of 617nm and a peak wavelength of 627nm at 20mA. This LED offers a luminous intensity of 8mcd at 20mA, a 120° viewing angle, forward voltage of 2V, and forward current of 20mA. It has a water-clear lens, making it suitable for backlight, indicator, and portable device applications, with RoHS compliance ensuring environmental safety.
KINGBRIGHT KPT3216EC High Efficiency Red LED Specifications:
- Size: 3.2mm x 1.6mm with 0.75mm thickness
- Emitting color: High efficiency red (GaAsP/GaP)
- Peak wavelength: 627nm at 20mA
- Dominant wavelength: 617nm at 20mA
- Luminous intensity: 8mcd at 20mA
- Viewing angle: 120°
- Forward voltage: 2V at 20mA
- Forward current: 20mA
- Spectral line half-width: 45 nm
- Capacitance: 15 pF
- Reverse current: 10 μA at 5V
- Operating temperature: -40°C to +85°C
- Storage temperature: -40°C to +85°C
- Package: 2000 pcs per reel
- RoHS compliant
- Reflow soldering profile recommended for lead-free process
Buy the Buy Kingbright High Efficiency Red Part Number KPT3216EC Online
Order the Kingbright High Efficiency Red LED today for superior brightness and reliability in electronic indicators, backlighting, and portable devices. Measuring 3.2mm by 1.6mm with a 120° viewing angle, it features a dominant wavelength of 617nm and peak at 627nm at 20mA. The LED has a water-clear lens, forward voltage of 2V, and a luminous intensity of 8mcd. Suitable for industrial, consumer, and embedded systems, it complies with RoHS standards. Available in reels for efficient manufacturing and installation.
Get Kingbright KPT-3216EC today—built for high efficiency, reliability, and excellent visibility in indicator and backlight applications.
Frequently Asked Questions
Where can I buy KINGBRIGHT KPT3216EC?
You can click on the BUY or RFQ button to purchase KPT3216EC from an authorized KINGBRIGHT distributor.
How do I troubleshoot issues or seek technical support for part KPT3216EC?
You can download the KPT3216EC datasheet or visit the KINGBRIGHT website for support.
Who is the manufacturer of KPT3216EC?
KINGBRIGHT
