KYOCERA AVX SCMU33F156SRBA0 Supercapacitor Module
The SCMU33F156SRBA0 is a series-connected supercapacitor module suitable for energy harvesting, pulse power, and backup applications. It features high capacitance, low ESR, and operates in a temperature range of -40°C to +65°C, with derating to extend to 85°C. Designed with robust mechanical and electrical specifications, it ensures reliable performance under various conditions. The module’s construction includes straight or bent leads with shrink wrap, adhering to safety and RoHS standards, making it ideal for industrial, wireless alarms, remote metering, and consumer electronics requiring high pulse power and longevity.
KYOCERA AVX SCMU33F156SRBA0 Supercapacitor Module Specifications:
- Voltage: 6.0V
- Capacitance: 15F (156) ±30%/-10%
- Operating Temperature Range: -40°C to +65°C, extended to 85°C with derating
- ESR: ≤200% of specified value
- Life Cycle: 500,000 cycles at rated/half-rated voltage
- Storage Duration: 2 years at room temperature
- Leakage Current: within manufactuer specifications
- Mechanical: Shrink wrap type, straight or bent leads, with dielectric strength and safety features
- Compliance: RoHS, REACH, UL810A
- Physical: Diameter 15mm, height approximately 20mm (typical)
- Soldering: Hand and wave soldering compatible, with precautions to avoid overheating
Buy the Kyocera Series SCM SuperCapacitor: SCMU33F156SRBA0
Purchase the Kyocera supercapacitor module online today and benefit from high capacitance, low ESR, and extended lifetime capabilities. This series-connected module is ideal for energy harvesting, backup systems, pulse power needs, and industrial environments. It features robust construction, RoHS compliance, and reliable performance from -40°C to +65°C, with derating to allow operation up to 85°C. Perfect for wireless alarms, remote metering, and consumer electronics, ensuring your project has long-lasting power and stability.
Buy Kyocera SCMU33F156SRBA0 supercapacitor module now and experience reliable energy storage with low ESR for long-lasting industrial and consumer applications.
Frequently Asked Questions
Where can I buy KYOCERA AVX SCMU33F156SRBA0?
You can click on the BUY or RFQ button to purchase SCMU33F156SRBA0 from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part SCMU33F156SRBA0?
You can download the SCMU33F156SRBA0 datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of SCMU33F156SRBA0?
KYOCERA AVX
