KYOCERA AVX TPSD336K035T0300V Tantalum Capacitor
This tantalum capacitor features a nominal capacitance of 33 uF with a tolerance of K = 410% and M = 420%. Rated for 35V DC operation at temperatures from -55°C to +125°C, it offers low equivalent series resistance (ESR) max 0.3 Ohm at 100kHz and high reliability with RoHS compliance and AEC-Q200 standards. Designed with low ESR and low leakage current (max 11.6 pA), it supports automotive and industrial applications, including low ESR automotive low ESR series, with robust performance under surge current testing and moisture sensitivity level 3. Compact case dimensions and lead-free construction ensure optimal integration in electronic designs.
KYOCERA AVX TPSD336K035T0300V Tantalum Capacitor Specifications:
- Capacitance: 33 uF
- Capacitance Tolerance: K = 410%, M = 420%
- Rated Voltage DC: 35V at < 85°C
- Category Voltage DC: 23V at < 125°C
- Surge Voltage: 46V at < 85°C, 28V at 125°C
- Temperature Range: -55°C to +125°C
- Leakage Current Max: 11.6 pA
- Dissipation Factor Max: 6% at 120Hz
- ESR Max: 0.3 Ohm at 100kHz
- Ripple Current RMS @100kHz: 707 mA at 25°C, 636 mA at 85°C, 283 mA at 125°C
- Ripple Voltage RMS @100kHz: 212 mV at 25°C, 191 mV at 85°C, 85 mV at 125°C
- Weight: 290 mg
- Moisture Sensitivity Level: MSL 3
- RoHS and lead-free compliant
- Reflow standard: J-STD-020
- Meets AEC-Q200 standards
- Case Dimensions: Length 7.3 mm, Width 4.3 mm, Height 2.9 mm
- Reel Packaging: 500 units (7" reel), 2500 units (13" reel), Tape width 12mm
- Material: RoHS-compliant tantalum with low ESR characteristics
Buy the AVX Series Low ESR Tantalum Capacitor: TPSD336K035T0300V
Purchase the AVX TPSD336K035T0300V tantalum capacitor online today for high performance, low ESR, and reliable operation in demanding automotive and industrial electronic systems. This component offers a capacitance of 33 uF with a voltage rating of 35V, meeting strict RoHS and AEC-Q200 standards. Its small case size and lead-free construction make it ideal for compact, environmentally conscious designs. Ensure your projects benefit from proven durability, excellent thermal stability, and low leakage current by ordering this high-quality low ESR tantalum capacitor online today.
Buy AVX TPSD336K035T0300V tantalum capacitor now and experience unmatched reliability and performance in automotive and industrial applications.
Frequently Asked Questions
Where can I buy KYOCERA AVX TPSD336K035T0300V?
You can click on the BUY or RFQ button to purchase TPSD336K035T0300V from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part TPSD336K035T0300V?
You can download the TPSD336K035T0300V datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of TPSD336K035T0300V?
KYOCERA AVX
