KYOCERA AVX TPSE227K016T0150V Low ESR Tantalum Capacitor
The Tantalum Low ESR Capacitor series offers reliable performance with 220 UF capacitance at 120Hz, rated at 16V DC, and operating within -55°C to +125°C temperature range. Designed for automotive applications, these RoHS-compliant capacitors feature low leakage current (35.2 μA), low ESR of 0.15 Ohm at 100kHz, and meet industry standards like J-STD-020 and AEC-Q200. They have a compact case size, weigh approximately 512mg, and are tested for 100% surge current, ensuring high durability and stability in demanding environments.
KYOCERA AVX TPSE227K016T0150V Low ESR Tantalum Capacitor Specifications:
- Capacitance: 220 UF @ 120Hz
- Capacitance Tolerance: K = 410%; M = +20%
- Rated Voltage DC: 16V (< 85°C)
- Category Voltage DC: 10V (< 125°C)
- Surge Voltage: 20V (< 85°C), 13V (125°C)
- Temperature Range: -55°C to +125°C
- Leakage Current Max: 35.2 μA
- Dissipation Factor Max: 10% @ 120Hz
- ESR Max: 0.15 Ohm @ 100kHz
- Weight: approximately 512 mg
- Reflow Standard: meets J-STD-020
- RoHS and Lead-Free Compliant
- Ripple Current RMS: 1049 mA at 25°C, 944 mA at 85°C, 420 mA at 125°C
- Packaging Options: T=7" Reel, U=13" Reel, 400 or 1500 quantity
- Case Dimensions: Length 7.3mm, Width 4.3mm, Height 41mm, Lead Spacing 1.3mm
- Surge Test: 100% tested for surge current
- Standards: Meets AEC-Q200 and industry reliability standards
Buy the Tantalum Series IND Low ESR Capacitor: TPSE227K016T0150V
Purchase the AVX Low ESR Tantalum Capacitor today for reliable, high-performance power filtering in automotive and industrial electronics. Featuring 220 UF capacitance with 16V rating, low ESR of 0.15 Ohm, and extensive testing including surge current, these capacitors are RoHS compliant and guarantee durability in high-temperature conditions up to +125°C. Their compact size and lead-free design make them ideal for space-constrained applications. Order online now for fast delivery, ensuring your electronic systems operate smoothly with premium quality components tailored for harsh environments.
Get AVX Tantalum Low ESR Capacitor TPSE227K016T0150V today—built for automotive reliability and peak performance in demanding environments.
Frequently Asked Questions
Where can I buy KYOCERA AVX TPSE227K016T0150V?
You can click on the BUY or RFQ button to purchase TPSE227K016T0150V from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part TPSE227K016T0150V?
You can download the TPSE227K016T0150V datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of TPSE227K016T0150V?
KYOCERA AVX
