KYOCERA AVX TPSE476K035T0250V Low ESR Tantalum Capacitor
This low ESR tantalum capacitor is designed for automotive and industrial applications, offering stable performance at voltages up to 35V and temperatures from -55°C to +125°C. It features a capacitance of 47µF with ±10% tolerance, high surge current capacity, and RoHS compliance. The capacitor ensures low leakage current, meets J-STD-020 reflow standards, and is RoHS lead-free. Its compact size and reliable low ESR make it ideal for power circuitry, automotive electronics, and high-frequency circuits requiring stable capacitance and high reliability.
KYOCERA AVX TPSE476K035T0250V Low ESR Tantalum Capacitor Specifications:
- Capacitance: 47µF at 120Hz
- Capacitance Tolerance: K = ±10%, M = ±20%
- Rated Voltage DC: 35V (< 85°C)
- Category Voltage DC: 23V (< 125°C)
- Surge Voltage: up to 46V
- Temperature Range: -55°C to +125°C
- Leakage Current Max: 16.5 pA at rated voltage
- Dissipation Factor Max: 6% at 120Hz
- ESR Max: 0.25 Ohm at 100kHz
- Weight: 512mg
- Moisture Sensitivity Level: RoHS compliant, MSL 3
- Reflow Standard: J-STD-020
- Surge Current: 100% tested
- Ripple Current RMS at 100kHz: 812mA at 25°C
- Reel Packaging: T=7" Reel: 400 pieces, U=13" Reel: 1500 pieces
- Case Dimensions: 7.3mm x 4.3mm x 41mm
- Lead-free: Yes
Buy the Buy AVX Tantalum Low ESR Capacitor Part Number TPSE476K035T0250V Online
Discover the high-performance AVX Tantalum Low ESR Capacitor, designed for automotive and industrial electronics. With a capacitance of 47 microfarads and rated at 35V, it offers exceptional stability, low leakage, and RoHS compliance. Its small form factor and high surge current capacity make it ideal for power supply circuits, high-frequency electronics, and demanding applications. Easy to order online, this capacitor ensures durability, reliability, and optimal performance in challenging environments. Get yours today for your critical electronic projects.
Order your AVX SeriesTPSE476K035T0250V tantalum capacitor today and enhance your automotive and industrial circuits with high reliability and low ESR performance.
