L-COM TRD815CH721F Industrial Twisted Pair Cable
This product is a high-quality, insulated twisted pair cable designed for telecommunications and industrial applications. It features 26 AWG stranded tin-plated copper conductors, high-density polyethylene insulation with an .008 inch wall, and polyurethane jacketing for durability. The cable boasts a maximum temperature rating of 60°C and a minimum of -20°C, with a voltage capacity of 300V and a dielectric withstand of at least 1500V RMS. Available in various lengths from 0.5 to 24 feet, it is color-coded and suitable for reliable electrical connectivity in demanding environments.
L-COM TRD815CH721F Industrial Twisted Pair Cable Specifications:
- Conductor: 26 AWG stranded tin-plated copper
- Insulation: High-density polyethylene, .008 inch wall
- Jacket: Polyurethane, black, .040 inch wall
- Temperature Rating: Max 60°C, Min -20°C
- Voltage Rating: 300V
- Dielectric Withstand: Min 1500V RMS
- Cable Diameter: Approx. .240 inch
- Shielding: Over cable core with tissue separator
- Color Code: White/Blue, White/Orange, White/Green, White/Brown
- Twisted pairs: 4 pairs twisted into a cable core
- Length options: 0.5 feet to 24 feet
- Maximum resistance: 42.6 ohm per 1000 feet
Buy the Buy High-Quality Insulated Twisted Pair Cable Part Number TRD815CH721F Online
Order the durable TRD815CH721F insulated twisted pair cable online today for reliable electrical connections in industrial and telecom applications. Featuring 26 AWG stranded tin-plated copper conductors, high-density polyethylene insulation, and a polyurethane jacket, this cable is designed to withstand temperature extremes from -20°C to 60°C. It offers a maximum voltage of 300V and dielectric withstand of at least 1500V RMS, ensuring safe and effective operation. Available in multiple lengths with color coding, this cable provides superior flexibility and durability for demanding environments.
Get TRD815CH721F high-durability twisted pair cable today—perfect for industrial and telecom wiring with excellent heat resistance and electrical performance.
