Littelfuse 0225007HXUP Fast Acting Axial Fuse
LITTELFUSE 224/225 Series Fast Acting Fuses are designed for supplementary protection in appliance and utilization equipment. Available in both axial lead and cartridge forms, these fuses provide reliable overcurrent protection while occupying minimal space. They are RoHS compliant, UL 248-14 certified, and offer a range of voltage and current ratings to suit various applications. The fuses are marked with brand logo, current and voltage ratings, and series and agency approval marks, ensuring easy identification and traceability.
Littelfuse 0225007HXUP Fast Acting Axial Fuse Specifications:
- Ampere Range: 0.375A - 10A
- Voltage Rating: 125V - 250V
- Interrupting Rating: 10A with 500A @ 125 Vdc
- Body Material: Glass
- Cap Material: Nickel-plated brass
- Lead Material: Tin-plated Copper
- Operating Temperature: –55ºC to 125ºC
- Thermal Shock: MIL-STD-202, Method 107
- Vibration: MIL-STD-202, Method 201
- Humidity: MIL-STD-202, Method 103
- Salt Spray: MIL-STD-202, Method 101
- Terminal Strength: MIL-STD-202, Method 211
- Solderability: MIL-STD-202 Method 208
- Packaging Quantity: 1000 (MX)
- Taping Width: 53mm (2.087”)
