Littelfuse 0498030M High Current Fuse
This high current bolt-down fuse features diffusion pill technology for reliable time delay protection in high-current applications. Rated at 32V with an interrupting rating of 1000A @ 32 VDC, it offers a compact design suitable for space-saving installations. Made with durable materials including tin-plated copper terminals and PA-GF25FR housing, it supports operating temperatures from -40°C to +125°C. Compliant with ISO 8620-5:2003 and UL 248 standards, it provides secure mounting with tightening torque of 4.5Nm ± 1Nm (M5) and 6.0 Nm ± 1Nm (M6). The fuse is available in various sizes and colors for different circuit requirements, ensuring safety and performance in demanding environments.
Littelfuse 0498030M High Current Fuse Specifications:
- Voltage Rating: 32V
- Interrupting Rating: 1000A @ 32 VDC
- Operating Temperature Range: -40°C to +125°C
- Housing Material: PA-GF25FR
- Terminal Material: Tin-plated Copper
- Mounting Torque: M5 4.5 Nm ± 1 Nm, M6 6.0 Nm ± 1 Nm
- Standards: ISO 8620-5:2003, UL 248
- Dimensions (mm): Length 4.0, Width 4.0, Height 8.0
- Color Options: Black, Clear
- Applicable Sizes: M5, M6 mounting holes
- Material features: High-temp resistance, diffusion pill time delay technology
Buy the Littelfuse Series MIDI High Current Fuse: 0498030M
Secure your electrical systems with the reliable high current bolt-down fuse designed for demanding environments. Rated at 32V and 1000A, this fuse ensures robust protection with diffusion pill time delay technology. Made from durable materials like tin-plated copper and high-temp resistant housing, it supports operating temperatures from -40°C to +125°C. Easy to install with M5 or M6 mounting options, it complies with industry standards for safety. Order online now to enhance your circuit protection with this high-performance fuse, ensuring safety and reliability in all applications.
Buy Littelfuse 0498030M now and experience unmatched reliability and performance for your high-current wiring protection needs.
Frequently Asked Questions
Where can I buy Littelfuse 0498030M?
You can click on the BUY or RFQ button to purchase 0498030M from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part 0498030M?
You can download the 0498030M datasheet or visit the Littelfuse website for support.
Who is the manufacturer of 0498030M?
Littelfuse
