Littelfuse 2920L26024DR Surface Mount PTC Thermistor
The 2920L series is a surface-mount PTC thermistor providing reliable overcurrent protection for medium voltage applications under 60V, such as telecom, automotive, and Ethernet ports. These resettable devices feature RoHS compliance, halogen-free materials, and fast fault response. They are designed to withstand high voltage, offer low-profile packaging, and are ideal for protecting sensitive electronic equipment by limiting current during overcurrent faults, preventing damage, and ensuring safe operation in various electronic systems.
Littelfuse 2920L26024DR Surface Mount PTC Thermistor Specifications:
- Environmental Operating Temperature: -40°C to +85°C
- Maximum Device Surface Temperature in Tripped State: 125°C
- Hold Current (A): 2.60 at 40°C, 2.08 at 85°C
- Maximum Resistance at 20°C: 0.075 Ω
- Resistance Range: 0.025 Ω to 0.085 Ω depending on model
- Maximum Voltage: 250V to 600V, varies per model
- Peak Current: Up to 260A for selected models
- Solder Material: Matte Tin (Sn)
- Solderability: Meets EIA RS186-9, ANSI/J-STD-002 Category 3
- Physical Dimensions: Approximately 6.73 mm x 0.75 mm x 0.25 mm (length x width x height)
Buy the Littelfuse Series 2920L Overcurrent Protection: 2920L26024DR
Purchase Littelfuse 2920L26024DR online and ensure reliable overcurrent protection for your electronic devices. Designed for quick response, RoHS compliance, and high voltage endurance, this surface-mount PTC thermistor is ideal for telecom, automotive, and Ethernet port protection. Simplify your assembly process with easy solderability and robust physical design. Whether updating existing systems or designing new equipment, order online today to secure fast delivery and excellent customer support from trusted electronic components suppliers.
Get Littelfuse 2920L26024DR today—built for precision and long-lasting durability in electronic protection systems.
Frequently Asked Questions
Where can I buy Littelfuse 2920L26024DR?
You can click on the BUY or RFQ button to purchase 2920L26024DR from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part 2920L26024DR?
You can download the 2920L26024DR datasheet or visit the Littelfuse website for support.
Who is the manufacturer of 2920L26024DR?
Littelfuse
