Littelfuse CCMR020TXP Motor Protection Fuse
This motor protection fuse ensures reliable performance in safety and control systems, designed specifically for space-saving motor protection up to 40 hp. Rated at 600 V with a 300 KA interrupting capacity, it features a dual-element, time-delay function suitable for withstands sustained starting currents of small motors. Its compact size and current-limiting properties make it an ideal choice for motor branch circuit protection in various industrial applications, providing efficient and UL-listed performance for electrical safety.
Littelfuse CCMR020TXP Motor Protection Fuse Specifications:
- Voltage Rating AC: 600V
- DC: 250V (CCMR 2/1n—2 A), 300V (CCMR 41/10 A), 600V (other models)
- Interrupting Rating: 300 KA (AC), 20 KA (DC)
- Amperage Ratings: 2-60A
- Dimensions: 1.50 inches (38.1 mm) length
- Features: Dual-element, time-delay, current-limiting
- Application: Motor and motor branch circuit protection
- Standards: UL Listed (248-4, 248), CSA Certified
- Environmental Compliance: RoHS
Buy the Littelfuse Series CCMR Motor Protection Fuse: CCMR020TXP
Purchase the Littelfuse CCMR020TXP motor protection fuse online today for superior safety and reliability in motor drive applications. Designed for space-efficient protection up to 600V, it features dual-element, time-delay technology that withstands starting currents of small motors. With a high interrupting capacity of 300 KA and UL listing, this fuse ensures protection for motor circuits in various industrial environments. Easy to install, RoHS compliant, and ideal for safeguarding motors from overloads and faults, securing continuous operation and electrical safety.
Buy Littelfuse CCMR020TXP now and experience unmatched reliability and high current-limiting performance for motor circuit protection.
Frequently Asked Questions
Where can I buy Littelfuse CCMR020TXP?
You can click on the BUY or RFQ button to purchase CCMR020TXP from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part CCMR020TXP?
You can download the CCMR020TXP datasheet or visit the Littelfuse website for support.
Who is the manufacturer of CCMR020TXP?
Littelfuse
