Littelfuse PSR030FS0200Z Power Semiconductor Fuse
Littelfuse PSR Series high-speed square body fuses provide reliable overcurrent protection for power semiconductor devices such as IGBTs, diodes, and SCRs. Designed for power conversion and conditioning equipment like VFDs, inverters, UPS, and soft starters, these fuses feature ultra-fast response times, high current limiting, and excellent cycling capability. Certified by UL, IEC, and CCC, they offer a robust ceramic body, plated brass contacts, and optional visual or microswitch blow indicators, ensuring dependable protection in demanding industrial applications.
Littelfuse PSR030FS0200Z Power Semiconductor Fuse Specifications:
- Voltage Range AC: 550 V - 1300 V
- DC: 500 V - 1000 V
- Amperage Range: 40A-2000A
- Interrupting Range AC: 100 kA - 200 kA
- DC: 150 kA
- Time Constant: 10ms
- Mounting: Flush-End Style
- Material Body: Ceramic
- Contacts: Plated Brass
- Approval: UL 248-13 Recognized, C-UR-US, IEC 60269-4, RoHS, REACH
- Operating Temperature: -55°C to +125°C
- Storage Temperature: Up to +35°C with <65% Humidity
- Certifications: UL, cUL, IEC, CCC
Buy the Buy Littelfuse Power Semiconductor Fuses Part Number PSR030FS0200Z Online
Secure your critical power conversion and conditioning equipment today by purchasing the Littelfuse PSR Series high-speed fuse online. Designed for protection of IGBTs, diodes, SCRs, and other solid state devices, this fuse features rapid response times, high current limiting, and certified safety. Its ceramic body ensures durability, while optional visual and microswitch indicators help monitor fuse status easily. Compatible with industrial applications such as VFDs, inverters, UPS, and motor drives, it guarantees long-lasting protection and maximum operational safety for demanding power semiconductor systems.
Order your Littelfuse Series PSR030FS0200Z high-speed fuse today and protect your sensitive power semiconductor devices with reliable, ultra-fast circuit protection.
Frequently Asked Questions
Where can I buy Littelfuse PSR030FS0200Z?
You can click on the BUY or RFQ button to purchase PSR030FS0200Z from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part PSR030FS0200Z?
You can download the PSR030FS0200Z datasheet or visit the Littelfuse website for support.
Who is the manufacturer of PSR030FS0200Z?
Littelfuse
