Littelfuse RXEF025 PolySwitch Resettable Fuse
The RXEF025 is a radial leaded PolySwitch resettable fuse designed to protect electronic circuits by balancing voltage and limiting hold current to 50mA. It features a voltage rating of up to 72V, making it suitable for high-volume electronics assembly while helping meet regulatory standards. This device offers a fast trip time, low resistance, and a hold current of 250mA with a trip current of 500mA. It is constructed with tin-plated copper-clad steel and complies with UL94V-0 flammability ratings. The RXEF025 is ideal for applications in industrial, medical, test and measurement, audio, lighting, communications and networking, security, and consumer electronics sectors.
Littelfuse RXEF025 PolySwitch Resettable Fuse Specifications:
- Voltage Rating: up to 72V
- Hold Current: 50mA
- Trip Current: 500mA
- Maximum Operating Temperature: 85°C
- Flammability: UL 94V-0
- Lead Material: Tin-plated copper-clad steel
- Lead Size: 0.205mm² (24AWG)
- Solderability: ANSI/J-STD-002 Category 3
- Solder Heat Withstand: 10 seconds at 260°C +5°C
- Dimensions: Abscissa to plane 12.7mm, overall width 43mm, overall height 58mm
- Compliance: RoHS, ELV
Buy the TE Series RXEF: 72V PolySwitch Resettable Fuse - 50mA: RXEF025
Get the TE Series RXEF025 72V PolySwitch resettable fuse online today. Designed for high-volume electronics, it provides fast trip times, low resistance, and strong regulatory compliance. Perfect for industrial, medical, and consumer electronics, this fuse balances voltage, limits current, and features durable construction with tin-plated copper-steel leads. Easy to integrate in various applications, it ensures circuit safety and reliability. Purchase now for dependable overcurrent protection that meets international safety standards.
Order your TE Series RXEF025 72V PolySwitch fuse today and ensure reliable circuit protection with quick trip response and regulatory compliance.
Frequently Asked Questions
Where can I buy Littelfuse RXEF025?
You can click on the BUY or RFQ button to purchase RXEF025 from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part RXEF025?
You can download the RXEF025 datasheet or visit the Littelfuse website for support.
Who is the manufacturer of RXEF025?
Littelfuse
