Littelfuse SA30CA Transient Voltage Suppressor Diode
The SA Series transient voltage suppression diodes are axial leaded devices designed to protect sensitive electronic components from voltage transients caused by lightning and other events. With a peak pulse power capability of 500W at 10/1000us waveform, these compact chips feature fast response times, excellent clamping, and high temperature soldering support. Suitable for telecom, industrial, and consumer applications, they ensure reliable ESD, EFT, and surge protection, incorporating environmentally friendly, RoHS-compliant, lead-free packaging for safeguarding data lines and circuits against voltage spikes.
Littelfuse SA30CA Transient Voltage Suppressor Diode Specifications:
- Peak Pulse Power Dissipation: 500W at 10/1000us waveform
- Maximum Operating Voltage: Vc depends on model (e.g., SA30CA)
- Breakdown Voltage: Specific to model, typically around 30V for SA30CA
- Clamping Voltage: Measured at designated peak impulse currents, typically below Vb
- Reverse Leakage Current: Less than 1pA when Vmax >13V
- Forward Voltage Drop: Typical for unidirectional types at 35V, max 0.8V
- Operating Junction Temperature Range: -65°C to +175°C
- Maximum Instantaneous Forward Surge Current: 70A for 8.3ms sine wave
- Thermal Resistance Junction to Lead: 20°C/W
- Thermal Resistance Junction to Ambient: Data available upon request
- Package Type: DO-15 glass passivated chip in axial lead configuration
- Lead Finish: Tin-plated, RoHS compliant, halogen free
- Soldering Support: Reflow temperature max 260°C, wave soldering temp 265°C, 1-time only
- Certifications: UL Listed, IEC-61000-4-2 ESD up to 30kV
- Material: Passivated junction with epoxy encapsulation
- Mechanical: Weight approx 0.4g, size standard for axial packages
- Environmental: Temp range -65°C to +175°C, high temperature soldering support
Buy the Buy Littelfuse TVS Diode Part Number SA30CA Online
Protect your sensitive circuits with the Littelfuse SA30CA transient voltage suppression diode. This axial leaded device offers up to 500W peak pulse power, fast response, and high temperature soldering support, making it ideal for telecom, industrial, and consumer applications. Its environmentally friendly, RoHS-compliant design ensures safety and sustainability. Featuring excellent clamping capability and low leakage current, this diode safeguards against voltage transients caused by lightning and surges. Order online now to enhance your product reliability with proven protection technology.
Order your Littelfuse SA30CA series transient voltage suppressor diode today and ensure reliable lightning, ESD, and surge protection for your electronics.
Frequently Asked Questions
Where can I buy Littelfuse SA30CA?
You can click on the BUY or RFQ button to purchase SA30CA from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part SA30CA?
You can download the SA30CA datasheet or visit the Littelfuse website for support.
Who is the manufacturer of SA30CA?
Littelfuse
