Littelfuse V14H14AUTO Automotive MOV
The AUMOV Series Metal-Oxide Varistors (MOVs) provide reliable circuit protection for automotive and industrial applications. Featuring epoxy or phenolic coatings, these high surge current, radial leaded varistors are qualifed under AEC-0200, RoHS compliant, and available in various sizes from 5mm to 20mm. Designed to absorb electric transients, they withstand peak surge currents up to 5kA, operate in temperature ranges up to 125°C, and offer high energy absorption. Suitable for load dump, jump start, and sensitive electronics protection, these low voltage, high surge current MOVs ensure safety and durability across demanding environments.
Littelfuse V14H14AUTO Automotive MOV Specifications:
- Surge Current: Up to 5kA (8/20 us pulse)
- Peak Surge Voltage: Varies from 16V to 825VDC, 14VAC to 625VAC
- Operating Temperature Range: -40°C to +125°C
- Maximum Clamping Voltage: Ranges based on size from 14V to 825V
- Coating Options: Epoxy, Phenolic, Silicone (up to 125°C)
- Energy Absorption Capability: Up to 140 J
- Storage Temperature Range: -40°C to +150°C
- RoHS, halogen-free, lead-free, UL94V-0 compliant
- Physical Sizes: 5mm, 7mm, 10mm, 14mm, 20mm diameters
- Voltage Range: 16V to 825V DC / 14VAC to 625VAC
- Isolation Voltage: Up to 2500V (silicone/epoxy coatings), 500V (phenolic)
- Lead Configurations: Straight, crimped, in-line, under crimp
- Qualification: AEC-0200 (Table 10)
- Durability: Withstands high thermal cycling, moisture, and vibration
Buy the Littelfuse V14H14AUTO – Reliable Automotive MOV for Industrial Applications
Purchase the Littelfuse Series V14H14AUTO metal-oxide varistor online now to ensure your automotive and industrial systems are protected against voltage transients. These high surge current MOVs are designed to absorb large surges up to 5kA, with sizes from 5mm to 20mm diameters, and operate in a temperature range from -40°C to +125°C. Their coatings meet rigorous quality standards, ensuring durability, high energy absorption, and reliable performance. Easy to order, these MOVs provide unparalleled protection for sensitive electronics in demanding environments.
Order your Littelfuse Series V14H14AUTO automotive varistor today and give your electronics the dependable surge protection they deserve.
Frequently Asked Questions
Where can I buy Littelfuse V14H14AUTO?
You can click on the BUY or RFQ button to purchase V14H14AUTO from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part V14H14AUTO?
You can download the V14H14AUTO datasheet or visit the Littelfuse website for support.
Who is the manufacturer of V14H14AUTO?
Littelfuse
