Littelfuse V14H510AUTO Automotive Metal-Oxide Varistor
The V14H510AUTO is a 14mm automotive-grade metal-oxide varistor (MOV) designed for circuit protection against voltage transients and load dump conditions. This high surge current MOV features coatings meeting AEC-Q200 standards, with a wide voltage range from 95V to 510V. It offers excellent thermal cycle resistance, high energy absorption, and RoHS compliance. Ideal for protecting sensitive automotive electronics such as infotainment, body systems, and powertrain modules, ensuring reliable surge suppression in harsh environments.
Littelfuse V14H510AUTO Automotive Metal-Oxide Varistor Specifications:
- Size: 14mm disc diameter
- Peak Surge Current: up to 10,000A (8/20 us pulse)
- Voltage Range: 95V to 510V AC, 95V to 650V DC
- Clamping Voltage: varies with model, up to 950V
- Peak Pulse Power: 2100W
- Energy Rating: up to 50J
- Operating Temperature: -40°C to +125°C
- RoHS compliant
- Coatings: Phenolic, Silicone (meeting AEC-Q200 standards)
- Resistance to thermal cycles: 1000 cycles at 125°C
- Isolation Voltage: 500V to 2500V depending on coating
- Lead Material: Copper alloy
- Repetitive pulse capability: high endurance in load dump scenarios
Buy the Buy Littelfuse MOV V14H510AUTO Part Number V14H510AUTO Online
Protect your vehicle's electronic systems with the high-performance Littelfuse V14H510AUTO metal-oxide varistor. Designed for load dump, jump start, and surge conditions, this 14mm MOV offers high surge current capacity up to 10,000A and a broad voltage range. Its coatings conform to AEC-Q200 standards, providing excellent thermal cycling resistance and RoHS compliance. Easily install this reliable surge suppression component to safeguard sensitive infotainment, body electronics, and powertrain modules in harsh automotive environments. Purchase online today for superior transient protection.
Buy Littelfuse MOV V14H510AUTO now and experience unmatched reliability and performance in automotive transient suppression.
Frequently Asked Questions
Where can I buy Littelfuse V14H510AUTO?
You can click on the BUY or RFQ button to purchase V14H510AUTO from an authorized Littelfuse distributor.
How do I troubleshoot issues or seek technical support for part V14H510AUTO?
You can download the V14H510AUTO datasheet or visit the Littelfuse website for support.
Who is the manufacturer of V14H510AUTO?
Littelfuse
