MAXIM INTEGRATED / ANALOG DEVICES MAX19790ETX Dual Voltage Variable Attenuator
The MAX19790ETX+ is a dual-channel analog voltage variable attenuator designed for high-frequency applications from 250MHz to 4000MHz. It features two integrated 36-pin TQFN packages, each providing up to 22dB attenuation with a linear control slope of 10dB/V. When cascaded, the attenuators offer a total attenuation of 44dB with a combined slope of 20dB/V. The device operates within a supply voltage range of 4.75V to 5.25V and an temperature range from -40°C to 85°C. It boasts a low insertion loss of approximately 2.4dB at 1500MHz per attenuator, excellent attenuation flatness over wide frequency and attenuation settings, and a low supply current of 7.3mA. This monolithic IC is built using Maxim's SiGe BiCMOS process and is suitable for applications such as broadband systems, wireless infrastructure, digital and spread spectrum communication systems, LTE/WCDMA, WiMAX, satellite modems, microwave links, automatic level control, and transmitter/receiver gain control.
MAXIM INTEGRATED / ANALOG DEVICES MAX19790ETX Dual Voltage Variable Attenuator Specifications:
- Frequency Range: 250MHz to 4000MHz
- Attenuation Range: 22dB per attenuator, 44dB cascaded
- Insertion Loss: approximately 2.4dB at 1500MHz
- Control Slope: 10dB/V per attenuator, 20dB/V cascaded
- Power Supply Voltage: 4.75V to 5.25V
- Operating Temperature Range: -40°C to 85°C
- Supply Current: 7.3mA
- Package: 36-pin Thin QFN (6mm x 6mm x 0.8mm), Exposed Pad
- Built using Maxim's SiGe BiCMOS process
- Applications include broadband systems, wireless infrastructure, LTE/WCDMA, WiMAX, satellite modems, microwave links, automatic level control, gain/m gain control
Buy the Maxim MAX19790 U– Reliable High-Frequency Attenuator for Industrial Applications
Enhance your RF systems with the MAX19790 dual voltage variable attenuator, covering 250MHz to 4000MHz. Featuring cascaded 44dB attenuation, low insertion loss of about 2.4dB, and linear control slope, it’s ideal for broadband, wireless, satellite, and microwave applications. Its compact 36-pin QFN package with exposed pad ensures efficient thermal and RF grounding. Designed on Maxim’s advanced SiGe BiCMOS technology, it provides robust operation over -40°C to 85°C, consuming only 7.3mA of current, delivering high performance and reliability for demanding industrial RF systems.
Buy Maxim MAX19790 now and experience unmatched reliability and performance in high-frequency attenuation control.
Frequently Asked Questions
Where can I buy MAXIM INTEGRATED / ANALOG DEVICES MAX19790ETX?
You can click on the BUY or RFQ button to purchase MAX19790ETX from an authorized MAXIM INTEGRATED / ANALOG DEVICES distributor.
How do I troubleshoot issues or seek technical support for part MAX19790ETX?
You can download the MAX19790ETX datasheet or visit the MAXIM INTEGRATED / ANALOG DEVICES website for support.
Who is the manufacturer of MAX19790ETX?
MAXIM INTEGRATED / ANALOG DEVICES
