MAXIM INTEGRATED / ANALOG DEVICES MAX6673AXKT Temperature Sensor
The MAX6673AXK+T is a compact, low-current temperature sensor in a 5-pin SC-70 package. It provides a PWM output at 1.4 kHz, where the duty cycle encodes the ambient temperature. The sensor features a single-wire output to minimize pin usage when interfacing with microcontrollers. It operates with a supply voltage range of 2.4V to 5.5V and a temperature range from -40°C to 125°C. The device consumes a low typical supply current of 60µA. Applications include industrial sensing, environmental monitoring, HVAC, and process control. Please note that due to high market demand, lead times may be extended, and delivery dates are subject to change.
MAXIM INTEGRATED / ANALOG DEVICES MAX6673AXKT Temperature Sensor Specifications:
- Supply Voltage Range: 2.4V to 5.5V
- Temperature Range: -40°C to 125°C
- Supply Current: typically 60µA
- Package: 5-pin SC-70
- Output: PWM at 1.4kHz, duty cycle encodes temperature
- Output Type: Push-pull (MAX6673)
- Thermal Error: ±4°C (0°C to +125°C)
- Storage Temperature: -55°C to +125°C
- Junction Temperature: +150°C maximum
- Lead Temperature (soldering): +300°C for 10s
Buy the Buy MAXIM Integrated MAX6673AXK+T Part Number MAX6673AXKT Online
Order the MAX6673AXK+T PWM temperature sensor online today to ensure precise ambient temperature measurement for industrial, HVAC, and environmental applications. This low-current, high-accuracy sensor in a compact SC-70 package offers easy integration with microcontrollers through its single-wire PWM output at 1.4kHz. Powered by a voltage range of 2.4V to 5.5V, it measures temperatures from -40°C to 125°C with minimal power consumption. Enjoy quick delivery and excellent customer support when purchasing this reliable temperature measurement solution online.
Buy MAXIM Integrated MAX6673AXK+T now and experience unmatched accuracy and low power consumption for reliable temperature sensing.
Frequently Asked Questions
Where can I buy MAXIM INTEGRATED / ANALOG DEVICES MAX6673AXKT?
You can click on the BUY or RFQ button to purchase MAX6673AXKT from an authorized MAXIM INTEGRATED / ANALOG DEVICES distributor.
How do I troubleshoot issues or seek technical support for part MAX6673AXKT?
You can download the MAX6673AXKT datasheet or visit the MAXIM INTEGRATED / ANALOG DEVICES website for support.
Who is the manufacturer of MAX6673AXKT?
MAXIM INTEGRATED / ANALOG DEVICES
