MAXIM INTEGRATED / ANALOG DEVICES MAX8655ETN Step-Down Voltage Regulator
The MAX8655ETN+ from Maxim Integrated is a highly integrated, 25A step-down voltage regulator in a 56-pin TQFN package. It features an internal MOSFET and comprehensive power management capabilities, including wide input voltage range from 4.5V to 25V and adjustable output voltage from 0.7V to 5.5V. The device employs peak current-mode control with a selectable switching frequency of 200kHz to 1MHz, which can be externally synchronized. It offers adjustable current limiting based on inductor DC resistance or an external sense resistor for precise control, along with foldback current limiting for overload conditions. A reference input allows for high-accuracy external references or tracking applications. The regulator provides monotonic start-up, safe operation into prebiased outputs, and supports power sourcing and sinking currents suitable for DDR and other high-precision applications. Additional features include enable control, power-OK output, soft-start, overcurrent protection with latch or auto-recovery modes, and temperature operation from -40°C to +85°C. Designed for power management in networking, telecommunications, portable devices, servers, and workstations.
MAXIM INTEGRATED / ANALOG DEVICES MAX8655ETN Step-Down Voltage Regulator Specifications:
- Input Voltage Range: 4.5V to 25V
- Output Voltage Range: 0.7V to 5.5V adjustable
- Maximum Output Current: 25A
- Switching Frequency: 200kHz to 1MHz, externally synchronizable
- Thermal Operating Range: -40°C to +85°C
- Peak Current-Mode Control
- Foldback Current Limiting for overload conditions
- External Reference Input for high accuracy
- Monotonic startup with prebiased load support
- Enable, Soft-start, Power-OK features
- Overcurrent protection with latch or autorecovery mode
- Exposed pad for enhanced cooling
- Package: 56-pin TQFN (8mm x 8mm)
Buy the Maxim Series MAX8655 Step-Down Regulator: 25A Wide-Input, Internal MOSFET
Purchase the Maxim MAX8655 step-down regulator online today and ensure precise power delivery in your designs. Featuring internal MOSFETs and wide input capability, this 25A regulator supports applications from networking to servers. Its adjustable output, synchronization, and overload protection make it ideal for high-performance power management solutions. Effortlessly integrate this reliable component into your projects for enhanced efficiency, safety, and longevity. Shop now to benefit from quick delivery and technical support, and take your power systems to the next level.
Get Maxim MAX8655 today—built for high current, efficiency, and reliable power management in advanced electronic systems.
Frequently Asked Questions
Where can I buy MAXIM INTEGRATED / ANALOG DEVICES MAX8655ETN?
You can click on the BUY or RFQ button to purchase MAX8655ETN from an authorized MAXIM INTEGRATED / ANALOG DEVICES distributor.
How do I troubleshoot issues or seek technical support for part MAX8655ETN?
You can download the MAX8655ETN datasheet or visit the MAXIM INTEGRATED / ANALOG DEVICES website for support.
Who is the manufacturer of MAX8655ETN?
MAXIM INTEGRATED / ANALOG DEVICES
