MEAN WELL APV2512 LED Power Supply
The APV-25 series is a compact, 20W single output switching power supply designed for LED lighting and decorative fixtures. It features universal AC input, high efficiency, and protections against short circuit, overload, and over voltage. With a fully insulated plastic case, IP42 protection, and a Class 2 power unit classification, it offers reliable performance with low noise ripple and noise levels up to 150mVp-p. Suitable for indoor use, it has a wide operation temperature range and proven durability verified through full load burn-in tests. Its small size makes it ideal for tight installation spaces.
MEAN WELL APV2512 LED Power Supply Specifications:
- Input Voltage: 90~264VAC, 127~370VDC
- Output Power: 20W
- Output Voltage Options: 12V, 18V, 24V, 36V
- Rated Current: 3.5A (12V), 2.48A (18V), 1.684A (24V), 1.054A (36V)
- Ripple & Noise: Max. 150mVp-p
- Protections: Short circuit, Over load, Over voltage
- Efficiency: Up to 84%
- Operation Temperature: -30°C to +70°C
- Humidity: 20–90% RH, non-condensing
- Dimensions: 84 x 57 x 29.5 mm
- Certifications: UL, CSA, BIS, EAC, IP42
- Isolation Resistance: >100M Ohms at 500VDC
- MTBF: 692,800 hours
- Vibration: 10-500Hz, 2G, 60 min per axis
- Safety Standards: UL, CSA, BS, EAC, IP42
- Approvals ensure suitability for indoor LED lighting applications
Buy the Buy MEAN WELL 20W Single Output Switching Power Supply Part Number APV-2512 Online
Enhance your LED lighting setup with the MEAN WELL APV-2512 series 20W power supply. Featuring universal input voltage, high efficiency, and robust protections, it is ideal for decorative and signage applications. Its compact design, IP42 rating, and full load burn-in testing guarantee durability and dependable operation. Suitable for indoor environments, the power supply provides stable voltage output and maintains excellent performance across a wide temperature range. Order online today for fast delivery and trustworthy quality.
Order your MEAN WELL APV-2512 series 20W LED power supply today and ensure reliable, efficient performance for your illumination projects.
Frequently Asked Questions
Where can I buy MEAN WELL APV2512?
You can click on the BUY or RFQ button to purchase APV2512 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part APV2512?
You can download the APV2512 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of APV2512?
MEAN WELL
