MEAN WELL DDR60G12 Industrial DIN Rail Power Converter
The DDR-60 series is a compact, 60W DIN rail-mounted DC-DC converter designed for industrial control, automation, and communication systems. It features an ultra-slim width of 52.5mm, wide input voltage ranges of 9~36V or 18~75V, and operates efficiently across -40°C to +85°C. It includes full protections such as short circuit, overload, over voltage, and reverse polarity, with reinforced 4KVdc I/O isolation. Its output is adjustable (+10%), suitable for various voltage needs like 5V, 12V, 15V, and 24V, making it ideal for telecom, factory automation, and semiconductor fabrication applications.
MEAN WELL DDR60G12 Industrial DIN Rail Power Converter Specifications:
- Power Rating: 60W
- Input Voltage Range: 9~36V or 18~75V
- Output Voltage: 5V, 12V, 15V, 24V
- Output Current: 10.8A at 5V, 5A at 12V, 4A at 15V, 2.58A at 24V
- Ripple & Noise (max.): 75mVp-p to 400mVp-p depending on model
- Voltage Adjustment Range: 45-55V or 9-132V depending on output
- Efficiency (Typ.): 87.5% to 92%
- Operating Temperature: -40°C to +85°C
- Isolation: 4KVdc, reinforced
- Dimensions: 52.5mm width, 90mm height, 64.5mm depth
- Protection Features: Short circuit, overload, over voltage, reverse polarity, under voltage lockout
- Mounting: DIN rail TS-35/7.5 or TS-35/15
- Compliance: IEC 62368-1
Buy the Buy Mean Well DDR-60G12 Part Number DDR60G12 Online
Purchase the DDR-60 series DIN rail power converter online today to ensure reliable industrial control and automation systems. With ultra-wide input voltage ranges, high efficiency, and full protections including short circuit, overload, and reverse polarity, this 60W converter is ideal for factory automation, telecom, and semiconductor fabrication. Its adjustable output and wide temperature operation make it versatile for various applications. Order now and enjoy quick delivery, robust build quality, and trusted performance for your critical power needs.
Get Mean Well DDR-60G12 today—built for precision and long-lasting durability in industrial automation and power supply applications.
Frequently Asked Questions
Where can I buy MEAN WELL DDR60G12?
You can click on the BUY or RFQ button to purchase DDR60G12 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR60G12?
You can download the DDR60G12 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR60G12?
MEAN WELL
