MEAN WELL DPB09A05 DC-DC Converter Module
DPB09A05 series are 9W isolated and regulated DC-DC converters in SIP8 packages, designed for industrial and telecommunication applications. They feature high efficiency up to 89%, wide temperature operation from -40°C to +90°C, and 1.5KVDC input-output isolation. These modules support various input voltages from 9V to 75V and multiple output options including 5V, 12V, and 15V. They offer short circuit protection, remote ON/OFF control, and are suitable for distributed power systems, automation, and control electronics, delivering reliable power efficiently in demanding environments.
MEAN WELL DPB09A05 DC-DC Converter Module Specifications:
- Input Voltage Range: 9~75Vdc (9~18V, 18~36V, 36~75V)
- Output Voltage Options: 3.3V, 5V, 12V, 15V, 24V; Dual outputs include +5V/+12V/+15V
- Efficiency: Up to 89%
- Input-Output Isolation Voltage: 1.5KVDC
- Operating Temperature: -40°C to +90°C
- Ripple & Noise: 100mVp-p
- Line Regulation: 0.5%
- Load Regulation: 0.5%
- Short Circuit Protection: Continuous, automatic recovery
- Remote ON/OFF Control: Supported
- Switching Frequency: Min. 400KHz
- Dimensions: 24*9.6*11.2mm, SIP8 package
- Protection: Overload (120-250%), Fuse recommended
- Working Humidity: 20-90% RH non-condensing
- Storage Temp.: -40°C to +125°C
- Safety Standards: EAC TP TC 004 approved
- Isolation Resistance: 100MΩ @ 500VDC
- Vibration Resistance: 10-500Hz, 2G for 60 min along X, Y, Z axes
Buy the Meanwell DPB09A05 – Reliable DC-DC Converter for Industrial Applications
Enhance your power management with the high-quality, reliable DC-DC converter module from Meanwell. Designed for industrial, telecommunication, and automation systems, this 9W module offers wide input voltage ranges from 9V to 75V, with multiple output options including 5V, 12V, and 15V. It features high efficiency up to 89%, input-output isolation of 1.5KVDC, and operation over a temperature range of -40°C to +90°C. Ideal for distributed power systems, automation controls, and harsh environments, ensuring consistent power delivery with protections for overloads and short circuits.
Order your Meanwell Series DPB09A05 high-efficiency DC-DC converter today and ensure your project benefits from dependable power supply performance.
Frequently Asked Questions
Where can I buy MEAN WELL DPB09A05?
You can click on the BUY or RFQ button to purchase DPB09A05 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DPB09A05?
You can download the DPB09A05 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DPB09A05?
MEAN WELL
