MEAN WELL DR4515 Industrial Power Supply
The industrial DIN rail power supply provides a 45W single output with universal AC input, high efficiency, and protections against short circuit, overload, over voltage, and temperature. Designed for easy installation on TS-35/7.5 or 15 DIN rails, it features full load burn-in testing, an LED power indicator, and a fixed switching frequency of 100KHz. Suitable for industrial control systems, it operates in a temperature range of -10°C to +50°C, with high reliability and compliance with UL 508 safety standards, making it ideal for a wide range of industrial applications.
MEAN WELL DR4515 Industrial Power Supply Specifications:
- Input Voltage: 85~264VAC, 120~370VDC
- Power: 45W
- Output Voltage: 15V
- Current: 2A
- Ripple & Noise: 200mVp-p
- Efficiency: 77%
- Operating Temperature: -10°C to +50°C
- Cooling: Free air convection
- Protection: Short circuit, Over load, Over voltage, Over temperature
- Dimensions: 93mm x 78mm x 67mm
- Certifications: UL 508, TUV EN60950-1
- Isolation Resistance: 100M Ohms at 500VDC
- Vibration: 10-500Hz, 2G
- MTBF: 364.6K hours (MIL-HDBK-217F)
Buy the ANA DR4515 U–Reliable Industrial Power Supply for Industrial Applications
Purchase the ANA DR4515 industrial power supply online today to ensure reliable power delivery for your automation and control systems. Featuring a 45W output, universal AC input, and comprehensive protections, it guarantees safe and efficient operation in demanding industrial environments. Easy to install on standard DIN rails TS-35/7.5 or 15, this power supply is UL approved and tested for full load operation. Secure your industrial setup with this high-quality power source, available for quick online ordering and fast delivery.
Buy ANA DR4515 now and experience unmatched reliability and performance for industrial control systems and automation projects.
Frequently Asked Questions
Where can I buy MEAN WELL DR4515?
You can click on the BUY or RFQ button to purchase DR4515 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DR4515?
You can download the DR4515 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DR4515?
MEAN WELL
