MEAN WELL GSM36B48P1J Medical Power Adapter
The GSM36B48P1J is a high-reliability, medical-grade 36W power adapter designed for portable and bedside medical devices. It supports universal AC input from 80VAC to 264VAC and delivers an output voltage of 48VDC at 0.75A, with high efficiency of up to 88% and ultra-low leakage current below 50uA. This certified Class II power supply features full isolation, protective features like over-voltage and short circuit protection, and complies with international medical safety standards (2 x MOPP). Its robust plastic case, LED indicator, and optional lockable DC plug make it suitable for demanding medical environments, ensuring safety and reliability.
MEAN WELL GSM36B48P1J Medical Power Adapter Specifications:
- Input Range: 80VAC to 264VAC, 47-63Hz
- Output Voltage: 48VDC
- Rated Current: 0.75A
- Rated Power: 36W
- Ripple & Noise: 240mVp-p
- Voltage Tolerance: ±2.0%
- Line Regulation: ±1.0%
- Load Regulation: ±2.0%
- Efficiency: Up to 88%
- Leakage Current: <50uA
- Protection: Over-voltage, Short circuit, Overload
- Operating Temperature: -25°C to +60°C
- Storage Temp: -40°C to +85°C
- Dimensions: 79 x 54 x 33 mm
- Housing: Fully enclosed plastic case
- Certifications: UL60601-1, TUV EN60601-1
- Insulation: Double insulation (2 x MOPP)
Buy the Medical Power Supply 36W – Reliable Medical Adapter for Industrial Applications
Order the GSM36B48P1J medical power adapter today and ensure your portable medical devices operate safely and efficiently. This 36W high-reliability adapter features a 48VDC output, excellent efficiency up to 88%, and ultra-low leakage current below 50uA, fully compliant with international medical safety standards. Its robust plastic enclosure, LED indicator, and optional locking DC plug enhance safety and ease of use. Designed for demanding environments, this power supply provides stable, protected power to medical devices, ensuring longevity and safety for both patients and healthcare providers.
Buy GSM36B48P1J now and experience unmatched reliability and performance in medical device power solutions.
Frequently Asked Questions
Where can I buy MEAN WELL GSM36B48P1J?
You can click on the BUY or RFQ button to purchase GSM36B48P1J from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part GSM36B48P1J?
You can download the GSM36B48P1J datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of GSM36B48P1J?
MEAN WELL
