MEAN WELL HEP24024A Industrial Power Supply
HEP-240 is a rugged 240W industrial power supply designed for harsh environments, offering high efficiency up to 93.5%, wide temperature range from -55°C to +70°C, and IP65/IP68 protection options. It features a fanless design with convection cooling, built-in active PFC, and protections against short circuit, overload, overvoltage, and temperature. Ideal for outdoor telecommunications, electronic signage, petroleum, and mining use, its robust aluminum case and silicone potting ensure durability and reliable operation at altitudes up to 5000 meters, meeting stringent EMC and safety standards.
MEAN WELL HEP24024A Industrial Power Supply Specifications:
- Power: 240W, Single output
- Input Voltage: 90~305VAC
- Output Voltages: 12V, 15V, 24V, 36V, 48V, 54V
- Rated Current: 16A (12V), 15A (15V), 6.87A (24V), 5A (36V), 4.45A (48V), 4.58A (54V)
- Ripple & Noise: Max. 150mVp-p (12V, 15V, 24V), 250mVp-p (36V, 48V), 350mVp-p (54V)
- Voltage Adjustment Range: 2.4~12.8V (12V),14~16V (15V), 2.4~25.8V (24V), 33.5~38.5V (36V), 44.8~51.2V (48V), 50~57V (54V)
- Voltage Tolerance: ±2.5% (12V), ±2.0% (15V), ±1.0% (24V, 36V, 48V, 54V)
- Efficiency: Up to 93.5%, full load at 230VAC
- Dimensions: 244.2mm (L) × 68mm (W) × 38.8mm (H)
- Protection: Short circuit, overload, overvoltage, over temperature
- Operating Temperature: -55°C to +70°C
- Operating Humidity: 20~95% RH (non-condensing)
- Vibration & Shock: Meets IEC standards, withstands 10G vibration
- Certifications: CE, UL, CB, IP65/IP68 options, surge immunity to 6KV
- MTBF: 171,300 hours minimum @ 25°C
Buy the Mean Well Series 240W Power Supply: HEP24024A
Purchase the 240W industrial power supply online today and ensure reliable operation in challenging environments. Featuring high efficiency up to 93.5%, wide temperature range from -55°C to +70°C, and robust IP65/IP68 protection, this unit is ideal for outdoor telecom, signage, and harsh industrial applications. Its fanless convection design reduces maintenance needs while providing stable power output across diverse conditions. Certified for safety and surge immunity, this power supply guarantees durability, safety, and energy efficiency—perfect for deployment in remote or demanding locations. Order now for fast worldwide shipping and expert support.
Get Mean Well 240W power supply today—built for precision and long-lasting durability in outdoor and industrial environments.
Frequently Asked Questions
Where can I buy MEAN WELL HEP24024A?
You can click on the BUY or RFQ button to purchase HEP24024A from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part HEP24024A?
You can download the HEP24024A datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of HEP24024A?
MEAN WELL
