MEAN WELL HLG185H36B High Power LED Driver
The HLG-185H series is a high-efficiency 185W LED driver with dual mode constant voltage and current operation, suitable for indoor and outdoor lighting applications. Operating from 90 to 305VAC with models spanning 12V to 54V, it features up to 94% efficiency and a fanless design for extended lifespan in temperatures from -40°C to +90°C. Its robust metal housing with IP67/IP65 ratings ensures durability against harsh environments, making it ideal for street and high-bay lighting, parking lights, and greenhouse illumination with multiple dimming options and a lifespan over 62,000 hours.
MEAN WELL HLG185H36B High Power LED Driver Specifications:
- Rated Power: 185W
- Input Voltage: 90~305VAC
- Output Voltage: 12V to 54V (varies by model)
- Rated Current: 13A at 12V, 11.54A at 15V, down to 3.45A at 54V
- Efficiency: Up to 94%
- Ripple & Noise: Max. 200mVp-p
- Protection: Over voltage, over temperature, short circuit, and over current protections
- Ingress Protection: IP67/IP65 rated for outdoor or indoor use
- Operating Temperature Range: -40°C to +90°C, derating as needed at higher altitudes
- Lifetime: Over 62,000 hours
- Certifications: UL, CSA, EN, EAC, KC, and others
- Mechanical Dimensions: 228mm x 68mm x 38.8mm
- Dimming Functionality: 3-in-1 dimming (1~10VDC, PWM, resistance) and potentiometer adjustment
- Housing: Metal with corrosion resistance
- Suitable for outdoor street, parking, high bay, greenhouse, and fishing lamps
Buy the Buy MEAN WELL 185W Constant Voltage + Constant Current LED Driver Part Number HLG185H36B Online
Enhance your lighting system with the MEAN WELL HLG185H36B, a 185W high-efficiency LED driver designed for outdoor and indoor environments. Featuring adjustable voltage and current, IP67/IP65 ratings, and a lifespan exceeding 62,000 hours, it offers reliable performance in temperatures from -40°C to +90°C. Its advanced dimming options, robust metal housing, and certifications ensure safe, energy-efficient operation for street, parking, high-bay, greenhouse, and fishing lighting applications. Purchase online today for dependable lighting solutions built for durability and performance.
Buy MEAN WELL HLG185H36B now and experience unmatched reliability and performance with advanced dimming and rugged outdoor design.
Frequently Asked Questions
Where can I buy MEAN WELL HLG185H36B?
You can click on the BUY or RFQ button to purchase HLG185H36B from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part HLG185H36B?
You can download the HLG185H36B datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of HLG185H36B?
MEAN WELL
