MEAN WELL HLG40H36B 40W LED Driver
The HLG-40H series is a 40W AC/DC LED driver designed for indoor and outdoor lighting applications, including street, high-bay, parking, greenhouse, and fishing lamps. It features dual-mode constant voltage and constant current output, efficiency up to 89.5%, and operates over a wide input voltage range of 90 to 305VAC. Its robust metal housing with IP67/IP65 ratings ensures durability in harsh environments. The series supports configurable dimming options, built-in active PFC, and a lifespan exceeding 62,000 hours, backed by a 7-year warranty, making it highly reliable for diverse LED lighting projects.
MEAN WELL HLG40H36B 40W LED Driver Specifications:
- Power: 40W
- Input Voltage: 90-305VAC, 127-431VDC
- Output Voltage: 12V to 54V (configurable models)
- Output Power: 40W
- Efficiency: Up to 89.5%
- Dimming: 1-10VDC, PWM, resistance, and timer options
- Ingress Protection: IP67/IP65
- Operating Temperature: -40°C to +80°C
- Lifetime: >62,000 hours
- Ripple & Noise: Max 300mVp-p
- Protection: Overload, short circuit, over voltage, over temperature
- Size: 171.6 x 36.8mm
- Certifications: UL, CSA, EN, IEC
- Power Factor: ≥0.95
- Surge & Transient: Compliant with industrial standards
- Mounting: Suitable for outdoor or indoor installation with waterproof connector
Buy the Mean Well Series 40W LED Driver: HLG40H36B
Discover the reliability and efficiency of the 40W LED driver from the acclaimed HLG series by Mean Well. Designed for diverse lighting applications, it features dual-mode output, high ingress protection, and a lifespan exceeding 62,000 hours. Its adjustable dimming, wide input voltage, and robust metal housing make it suitable for outdoor and indoor lighting needs. With certifications including UL and CSA, order online today to enhance your lighting solutions with this durable, high-performance LED driver, ensuring energy efficiency and long-term operation.
Order your Mean Well Series 40W LED Driver HLG40H36B today and ensure reliable performance for both indoor and outdoor lighting projects.
Frequently Asked Questions
Where can I buy MEAN WELL HLG40H36B?
You can click on the BUY or RFQ button to purchase HLG40H36B from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part HLG40H36B?
You can download the HLG40H36B datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of HLG40H36B?
MEAN WELL
