MEAN WELL IRM0315 3W Power Supply Module
IRM-03 series is a compact 3W AC-DC power supply module designed for industrial and electronic applications. It features universal input voltage of 85~305VAC, high efficiency up to 80%, and excellent EMI compliance with EN55022 Class B. The module is fully encapsulated, dust and moisture resistant, and offers protections against short circuit, overload, and over voltage. Its small size (37*24*15mm or 16mm for SMD), low no-load consumption below 0.075W, and wide operating temperature range (-30°C to +85°C) make it ideal for automation, instrumentation, and handheld devices.
MEAN WELL IRM0315 3W Power Supply Module Specifications:
- Input Voltage: 85~305VAC, 120~430VDC
- Output Power: 3W
- Output Voltage Options: 3.3V, 5V, 12V, 15V, 24V
- Rated Current: 900mA (3.3V), 600mA (5V), 333mA (12V), 250mA (15V), 200mA (24V)
- Ripple & Noise: 100mVp-p to 240mVp-p depending on model
- Voltage Tolerance: ±2.5%
- Line Regulation: 0.5%
- Load Regulation: 0.5% to 1.0%
- Efficiency: Up to 80%
- Operating Temp: -30°C to +85°C
- Humidity: 20~90% RH non-condensing
- Protection: Short circuit, Overload, Over voltage
- Isolation Voltage: 3k VAC (O/P to O/P)
- Dimensions: 37*24*15mm (PCB mounting), 37*24*16mm (SMD style)
Buy the Mean Well Series 3W AC-DC Power Supply: IRM0315
Order the reliable 3W power supply module online today to ensure your electronic projects or industrial equipment operate smoothly. With universal input, high efficiency up to 80%, and protections for short circuit, overload, and over voltage, this module guarantees safe and stable power delivery. Its compact size fits seamlessly into various applications, including automation systems, instrumentation, and handheld devices. Enjoy fast shipping, excellent customer support, and secure payment options for your convenience. Upgrade your power solutions with this versatile, durable module now.
Buy Mean Well IRM0315 now and experience unmatched reliability and performance with their compact, high-efficiency power modules suitable for industrial automation.
