MEAN WELL LPHC18700 Power Supply
The LPHC-18-700 is a fully encapsulated switching power supply rated at 25V and 17.5W output. It features IP67 ingress protection, ensuring durability and reliable operation in outdoor or harsh environments. Designed for LED lighting and moving sign applications, it operates in constant current mode, providing stable power delivery. The power supply is class II, has passed LPS safety standards, and has undergone full load burn testing. It offers excellent regulation with 3% load regulation and 1% line regulation, along with protections against short circuits, overvoltage, and over-temperature conditions. Cooling is achieved through free air convection, enhancing reliability for long-term use.
MEAN WELL LPHC18700 Power Supply Specifications:
- Fully encapsulated with IP67 level
- Rated Power: 17.5W
- DC Voltage Range: 6~25V
- Rated Current: 700mA
- Ripple & Noise (max.): 250mVp-p
- Voltage Tolerance: +5.0%
- Line Regulation: 1%
- Load Regulation: 3%
- Input Voltage: 180 ~ 264VAC or 254 ~ 370VDC
- Input Frequency Range: 47 ~ 63Hz
- Efficiency: 80%
- Protection: Short circuit, Over voltage, Over temperature
- Working Temperature: -30~+70°C
- Humidity: 20 ~ 90% RH non-condensing
- Storage Temp: -40~+80°C, 10~95% RH
- Vibration: 40 ~ 500Hz, 2G
- Safety Standards: IP67, UL1310 Class 2, TUV EN60950-1, CSA
- Withstand Voltage: 3KVAC
- Isolation Resistance: >100M Ohms /500VDC
- EMC Compliance: EN55022 Class B, EN61000-3-2, EN61000-3-3
- MTBF: 1200.6K hrs min. MIL-HDBK-217F
- Dimensions: 140mm x 30mm x 22mm
Buy the Buy ANA Power Supply Part Number LPHC-18-700 Online
Purchase the ANA LPHC-18-700 power supply online today to benefit from high reliability, IP67 protection, and advanced safety features. Perfect for outdoor LED lighting and signage applications, this fully encapsulated unit offers stable constant current output, excellent regulation, and comprehensive protections against short circuits, overvoltage, and over-temperature conditions. Its rugged design ensures durability in harsh environments, with proven efficiency and a long MTBF of over 1200 hours. Secure your project’s power needs confidently—order now and enjoy fast, reliable delivery of this essential power component.
Order your ANA Power Supply LPHC-18-700 today and ensure reliable, efficient power for your outdoor LED lighting and signage projects.
Frequently Asked Questions
Where can I buy MEAN WELL LPHC18700?
You can click on the BUY or RFQ button to purchase LPHC18700 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part LPHC18700?
You can download the LPHC18700 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of LPHC18700?
MEAN WELL
