MEAN WELL LRS3548 Power Supply Module
The LRS-35-48 series is a 35W single-output switching power supply with a compact 30mm low-profile design, enabling versatile industrial and household applications. Its wide AC input range (85-264VAC) supports 48V output at 0.8A rated current, providing high efficiency up to 89% and minimal no load consumption under 0.2W. Featuring robust protections, a metallic mesh case for enhanced heat dissipation, and operation from -30°C to 70°C, it complies with international safety standards. Suitable for automation, control systems, and electronic instruments, the power supply ensures reliability in demanding environments.
MEAN WELL LRS3548 Power Supply Module Specifications:
- Power output: 35W
- Input Voltage: 85-264VAC, 47-63Hz
- Output Voltage: 48V
- Rated Current: 0.8A
- Efficiency: Up to 89%
- Noise: 200mVp-p
- Operating Temperature: -30°C to 70°C
- Protection: Short circuit, overload, over voltage
- Dimensions: 99 x 82 x 30 mm
- Isolation Voltage: 3.75KVAC (input to output)
Buy the Mean Well Series 35W Power Supply: LRS3548
Enhance your project reliability with the Series 35W power supply from Mean Well. Featuring wide input range 85-264VAC, high efficiency up to 89%, and low no load power consumption, it is ideal for industrial automation, control systems, and home appliances. Its robust protections including short circuit, overload, and over voltage ensure safe operation, while the compact design and heat dissipation capabilities make it suitable for tight spaces and demanding environments. Purchase online today for dependable performance.
Order your Mean Well Series 35W power supply today and ensure reliable power for your industrial and household projects with excellent efficiency.
Frequently Asked Questions
Where can I buy MEAN WELL LRS3548?
You can click on the BUY or RFQ button to purchase LRS3548 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part LRS3548?
You can download the LRS3548 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of LRS3548?
MEAN WELL
