MEAN WELL PLN3024 LED Power Supply
The PLN-30 series 30W AC/DC LED power supply features a single output and a full-range universal input voltage, making it suitable for LED lighting and moving sign applications. It complies with worldwide safety standards and offers reliable performance with built-in active Power Factor Correction (PFC). The power supply includes protections against short circuits, over-current, over-voltage, and over-temperature conditions, ensuring safety and durability. It is cooled by free air convection and features a fully insulated plastic case with an IP64 rating, suitable for indoor and outdoor installations. The device is a class 2 power unit with no grounding (FG) and has undergone a 100% full load burn-in test for high reliability. Designed for power management and industrial applications.
MEAN WELL PLN3024 LED Power Supply Specifications:
- Power: 30W
- Input Voltage: 90~295VAC, 127~417VDC
- Output Voltage: 15V, 20V, 24V, 36V, 48V (various models)
- Rated Current: 33A at 15V, 2.5A at 20V, 1.25A at 24V, 0.84A at 36V, 0.63A at 48V
- Efficiency: up to 85.5%
- Ripple & Noise: 2.6Vp-p to 45Vp-p depending on model
- Protection: Short circuit, over-current, over-voltage, over-temperature
- Cooling: Free air convection
- Isolation: Fully isolated plastic case with IP64
- Protection Mode: Hiccup mode (short circuit), shut down (over-voltage and temperature)
- Temperature Range: -30°C to +50°C
- Humidity: 20% to 95% RH, non-condensing
- Dimensions: Approx. 145mm x 47mm x 30mm
- Certifications: UL, TUV, EN61347-1, EN61347-2-13, CSA, CE, RoHS
- MTBF: 621,400 hours
- Warranty: 2 years
Buy the Buy MEAN WELL PLN-30 Series Part Number PLN3024 Online
Purchase the MEAN WELL PLN-30 series LED power supply online and experience dependable power delivery for your LED lighting and sign projects. Designed with a universal input range, high efficiency up to 85.5%, and proven safety standards, it ensures long-lasting performance. Equipped with protections against short circuits, over-current, over-voltage, and temperature extremes, this 30W power supply is perfect for indoor and outdoor applications. Easy to install, fully insulated, IP64 rated, and tested for full load reliability, it is the ideal choice for professional lighting and signage solutions.
Get MEAN WELL PLN-30 series power supply today—built for reliable LED lighting and industrial power management with safety and efficiency.
Frequently Asked Questions
Where can I buy MEAN WELL PLN3024?
You can click on the BUY or RFQ button to purchase PLN3024 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part PLN3024?
You can download the PLN3024 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of PLN3024?
MEAN WELL
