MEAN WELL WDR6048 60W DIN Rail Power Supply
The MEAN WELL WDR-60 series is a 60W DIN rail power supply designed for industrial applications. It boasts an ultra-wide AC input range, making it suitable for various single-phase or two-phase systems. Key features include easy DIN rail mounting, a slim width, a wide operating temperature range (-30~+85°C), high isolation voltage (4.7kVAC), and adjustable output voltage. Compliant with EN-61000-6-2, the WDR-60 is ideal for industrial automation, surveillance, and telecommunication systems, offering reliable power with complete protections and a 3-year warranty.
MEAN WELL WDR6048 60W DIN Rail Power Supply Specifications:
- Rated Power: 60W
- DC Voltage: 48V
- Rated Current: 1.25A
- Output Voltage Adj. Range: 48 ~ 57V
- Line Regulation: ±1.0%
- Load Regulation: ±0.5%
- Setup, Rise, Hold Up Time: 58ms, 70ms, 20ms/400Vac
- Voltage Range: 180 ~ 550Vac or 254 ~ 780Vdc
- Frequency Range: 47 ~ 63Hz
- Efficiency (Typ.): 86.5% / 400Vac
- Inrush Current (max.): 0.4A/400Vac
- Leakage Current: <2mA / 530Vac
- Overload: 105 ~ 135% rated output power
- Over Voltage: 6.2 ~ 7.2V
- Safety Standards: UL61010, EN61558-2-16, EAC TP TC 004
- Working Temp.: -30 ~ +85°C
- DC OK Signal: Relay contact rating(max.) : 30V / 1A resistive
- Working Humidity: 20 ~ 90% RH non-condensing
- Storage Temp.: -40 ~ +85°C
- Vibration: 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
- MTBF: 313.68K hrs min.
Buy the WDR-60-48 MEAN WELL 60W DIN Rail Power Supply | myMectronic
Purchase the MEAN WELL WDR-60-48 securely and reliably for your industrial power needs.
Buy Now
Frequently Asked Questions
Where can I buy MEAN WELL WDR6048?
You can click on the BUY or RFQ button to purchase WDR6048 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part WDR6048?
You can download the WDR6048 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of WDR6048?
MEAN WELL
