MOLEX 1053101206 Nano-Fit Power Connector
The MOLEX 105310-1206 Nano-Fit Power Connector is a robust and reliable solution for power transmission in wire-to-board applications. This vertical header features a dual-row design with 6 circuits, offering a compact and efficient connection. The kinked pins enhance stability, while the gold-over-nickel plating on the mating interface ensures excellent conductivity and durability. Designed for a 2.50mm pitch, this connector is ideal for applications requiring high-density connections and is compatible with Nano-Fit receptacle housings. It is RoHS compliant and operates within a temperature range of -40°C to +115°C.
MOLEX 1053101206 Nano-Fit Power Connector Specifications:
- product_family: PCB Headers
- series: 105310
- application: Power, Wire-to-Board
- circuits_loaded: 6
- circuits_maximum: 6
- color_resin: Black
- durability_mating_cycles: 50
- flammability: 94V-0
- glow_wire_compliant: No
- guide_to_mating_part: Yes
- lock_to_mating_part: Yes
- material_metal: Brass
- material_plating_mating: Gold over Nickel
- material_plating_termination: Tin over Nickel
- material_resin: Liquid Crystal Polymer
- net_weight_g: 0.590
- number_of_rows: 2
- orientation: Vertical
- pc_tail_length_mm: 3.20
- pcb_locator: Yes
- pcb_retention: Yes
- pcb_thickness_recommended_mm: 1.60, 2.40
- packaging_type: Tray
- pitch_mating_interface_mm: 2.50
- pitch_termination_interface_mm: 2.50
- plating_min_mating_um: 0.381
- plating_min_termination_um: 1.524
- polarized_to_mating_part: Yes
- polarized_to_pcb: Yes
- shrouded: Yes
- stackable: No
- surface_mount_compatible: No
- temperature_range_operating_c: -40 to +115
- termination_interface_style: Through Hole
- current_max_per_contact_a: 6.5
- voltage_max_v: 300
- upc: 887191933535
