MOLEX 1720650012 Power Connector
The Mega-Fit Power Connector series features a 5.70mm pitch vertical header with 12 circuits, gold plating, and UL 94 V-0 flame rating. Designed for power applications, it offers reliable wire-to-board connection with a mated height of 16.78mm, polarized and shrouded for secure mating, and compatible with surface mount technology. Made from high-temperature thermoplastic with copper metal, it supports operating temperatures from -40°C to +120°C. The connector ensures optimal electrical performance with maximum 23A current per contact and 600V voltage capacity, suitable for demanding industrial applications.
MOLEX 1720650012 Power Connector Specifications:
- Pitch: 5.70mm
- Circuits: 12
- Color: Black
- Material - Metal: Copper
- Material - Plating Mating: Gold (Au)
- Material - Plating Termination: Tin
- Flammability: UL 94 V-0
- Height (mated): 16.78mm
- Height (unmated): 14.03mm
- Operating Temperature Range: -40°C to +120°C
- Maximum Current per Contact: 23.0A
- Maximum Voltage: 600V
- Termination Interface: Through Hole
- Surface Mount Compatibility: Yes
- Polarized to Mating and PCB: Yes
- Shrouded: Yes
- Material: High-Temperature Thermoplastic
- Net Weight: 6.718g
- PCB Thickness Range: 1.57mm to 2.36mm
Buy the Molex 1720650012 – Reliable Power Connectors for Industrial Applications
Purchase the Molex Mega-Fit Power Connector online today—designed for reliable power connections in industrial settings. Featuring 12 circuits with a 5.70mm pitch, gold plating, and UL 94 V-0 flame rating, this connector ensures a secure and efficient connection. Its high-temperature thermoplastic body withstands temperatures from -40°C to +120°C, supporting up to 23A per contact at 600V. Compatible with surface-mount technology and polarized for secure mating, it is ideal for demanding power distribution and automation systems, providing durability, safety, and excellent electrical performance.
Get Molex 1720650012 today—built for precision and long-lasting durability in power and wire-to-board applications.
Frequently Asked Questions
Where can I buy MOLEX 1720650012?
You can click on the BUY or RFQ button to purchase 1720650012 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 1720650012?
You can download the 1720650012 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 1720650012?
MOLEX
