MOLEX 194290035 Industrial Sealed Connector
The MX150L industrial sealed connector system by Molex is designed for inside panel mount applications, providing IP67 ratings and UL 1977 compliance. This 4-circuit panel mount plug supports 14-22 AWG wire sizes and features a rear mount flange with a gasket for secure sealing. Made from black resin with UL 94V-0 flammability rating, it offers reliable performance in harsh environments, operating from -40°C to +125°C, and supporting a maximum current of 18A per contact. Suitable for power and wire-to-wire connections in industrial and equipment applications, the MX150L connector ensures rugged, durable electrical connections in challenging conditions.
MOLEX 194290035 Industrial Sealed Connector Specifications:
- Number of circuits: 4
- Wire Range: 14-22 AWG
- Color - Resin: Black
- Flammability: UL 94V-0
- Gender: Plug
- IP Rating: IP67
- Operating Temperature Range: -40°C to +125°C
- Maximum Current: 18.0A per contact
- Material: Plastic, UL 94V-0 rated
- Mounting: Panel mount with rear flange
- Assembly: Includes gasket for sealing
- Certifications: UL, UL 1977, RoHS, EU ELV, China RoHS, REACH SVHC not contained, Halogen-Free, Low-Halogen
Buy the Buy Molex MX150L Part Number 0194290035 Online
Purchase the Molex MX150L industrial sealed connector online today for robust, waterproof power connections in demanding industrial environments. This 4-circuit panel mount plug supports 14-22 AWG wires and features an IP67 rated enclosure with UL 1977 compliance, ensuring safety and durability. Its rear flange and gasket provide a secure seal against dust and moisture. Operating from -40°C to +125°C, with a maximum current of 18A per contact, it offers high-performance reliability for power and wire-to-wire applications in harsh conditions.
Get Molex MX150L 0194290035 today—built for industrial power and reliable sealing in harsh environments.
Frequently Asked Questions
Where can I buy MOLEX 194290035?
You can click on the BUY or RFQ button to purchase 194290035 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 194290035?
You can download the 194290035 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 194290035?
MOLEX
