MOLEX 2002772104 Nano-Fit Power Connectors
Nano-Fit Power Connectors provide compact, fully isolated headers with keying options for proper mating and contact assurance. Featuring a 2.50mm pitch, these connectors are ideal for space-constrained PCB applications across consumer, industrial, and aerospace sectors. They offer low mating force, high current capacity up to 6.54A, and reliable performance with 50 gold or 20 tin cycles. The connectors include terminal position assurance retainers, color-coded keying, and optional TPA for enhanced contact security, making assembly faster, more reliable, and suitable for high-density, multi-layered PCB designs.
MOLEX 2002772104 Nano-Fit Power Connectors Specifications:
- Voltage (Max.): 250V
- Current (Max.): 6.54A
- Contact Resistance: 10 milliohms change over life
- Dielectric Withstanding Voltage: 1500V
- Insulation Resistance: 1000 Megohms
- Contact Insertion Force: 2.5N
- Contact Retention to Housing: 27N
- Mating Force: 3N
- Unmating Force: 3N
- Durability: 20 cycles (tin), 50 cycles (gold)
- Housing Material: Nylon UL 94V-0 (receptacle), LCP UL 94V-0 (header)
- Contact Material: High-Conductivity Copper
- Plating: Tin or gold options
- PCB Thickness Range: 1.60 to 2.40mm
- Operating Temperature: -40°C to +115°C
- RoHS Compliant, Halogen Free, Glow-Wire Capable
Buy the Molex Series Nano-Fit Power Connectors: 2.50mm Pitch Part 2002772104
Purchase Molex Nano-Fit Power Connectors online today—these compact, high-performance connectors are designed for space-constrained PCB assemblies, ensuring reliable connections in consumer electronics, industrial equipment, and aerospace applications. With features like contact assurance, keying options, and low mating force, they facilitate easy and secure assembly. Available with gold or tin plating, TPA retainers, and color coding, these connectors help improve productivity, reduce assembly errors, and support long-term durability for demanding electronic systems.
Get Molex Nano-Fit Power Connectors today—built for space-efficient, reliable electronic assemblies with easy mating and contact assurance.
