MOLEX 2045320301 Micro-Lock Plus Receptacle
The Micro-Lock Plus Receptacle Housing is a compact, low-halogen, 1.25mm pitch connector designed for wire-to-board applications. Featuring a single row of 3 circuits, this black housing offers a positive lock to ensure secure connections. Certified by CSA and UL, it is suitable for versatile industrial and electronic use. Made from durable polyester resin, it operates within a temperature range of -40°C to +105°C, providing reliable performance in various environmental conditions. The connector system is compatible with Micro-Lock Plus headers and terminals, ensuring efficient assembly and maintenance.
MOLEX 2045320301 Micro-Lock Plus Receptacle Specifications:
- Pitch - Mating Interface: 1.25mm
- Circuits (maximum): 3
- Color - Resin: Black
- Gender: Receptacle
- Material - Resin: Polyester
- Temperature Range - Operating: -40°C to +105°C
- Number of Rows: 1
- Packaging Type: Bag
- Lock to Mating Part: Yes
- Mates With: Micro-Lock Plus Header 205957
- Use With: Micro-Lock Plus Terminal 505431
- Agency Certifications: CSA, UL
- RoHS Compliant: Yes
- Halogen-Free: Yes
Buy the Molex Series Micro-Lock Plus Wire-to-Board Connector: 2045320301
Purchase the Molex Micro-Lock Plus Receptacle Housing online today to ensure a reliable, low-halogen, 1.25mm pitch connector designed for efficient wire-to-board connections. Featuring a positive lock, high durability from polyester material, and certifications from CSA and UL, this black housing supports operating temperatures from -40°C to +105°C. Its compact single row design simplifies assembly in electronics and industrial equipment. Compatible with Micro-Lock Plus headers and terminals, it provides a secure, long-lasting connection ideal for demanding environments and professional manufacturing needs.
Get Molex 2045320301 today—built for precision, secure locking, and long-lasting durability in electronic and industrial applications.
