MOLEX 2147501083 Micro-Fit 3.0 Cable Assembly
The MOLEX 214750-1083 is a Micro-Fit 3.0 female-to-female cable assembly designed for power and wire-to-board or wire-to-wire connections. This assembly features a 600mm length, 8 circuits, and tin plating on both mating and termination interfaces. Constructed with phosphor bronze and nylon materials, it offers durability and reliable performance in various industrial applications. The assembly is RoHS compliant and supports a maximum current of 8.5A per contact, making it suitable for demanding electrical environments.
MOLEX 2147501083 Micro-Fit 3.0 Cable Assembly Specifications:
- Overview: Micro-Fit Connector System
- Application: Power, Wire-to-Board, Wire-to-Wire Assembly
- Configuration: Dual Ended
- Connectors: Connector to Connector Micro-Fit 3.0 Both Ends
- Cable Length: 600.00mm
- Circuits (Loaded): 8
- Color: Black
- Gender: Female-Female
- Lock to Mating Part: Yes
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin (Sn)
- Material - Plating Termination: Tin (Sn)
- Material - Resin: Nylon
- Net Weight: 56.453/g
- Number of Rows: 1
- Pitch - Mating Interface: 3.00mm
- Plating min - Mating: 1.016µm
- Plating min - Termination: 1.016µm
- Single Ended: No
- Wire Insulation Diameter: 1.85mm max.
- Wire Size AWG: 18
- Wire/Cable Type: Discrete Wire, UL 10002
- Current - Maximum per Contact: 8.5A
- EU ELV: Not Relevant
- EU RoHS: Compliant
- REACH SVHC: Not Contained
- Halogen-Free Status: Not Low-Halogen
- Mates With: Micro-Fit 3.0 Plug Housings (43640), Micro-Fit TPA Plug Housing (200875), Micro-Fit 3.0 Headers (43650)
- Reference - Drawing Numbers: Sales Drawing 2147501081-000
