MOLEX 2149211122 PicoBlade Connector Lead
The PicoBlade Female-to-Pigtail Pre-Crimped Lead is a 150mm long, tin-plated, red wire assembly designed for reliable connections. It features a female connector on one end and a pigtail on the other, suitable for PCB and wire harness applications. Constructed from phosphor bronze, it supports 28 AWG wire size, with a maximum current of 1.0A and voltage of 125V. This crimp lead ensures quick, secure connections for electronics and automation systems, offering RoHS compliance and halogen-free construction for enhanced environmental safety.
MOLEX 2149211122 PicoBlade Connector Lead Specifications:
- Cable Length: 150.00mm
- Circuits (Loaded): 1
- Color - Resin: Red
- Gender: Female-Pigtail
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Wire Size AWG: 28
- Wire Insulation Diameter: 1.04mm max.
- Voltage - Maximum: 125V AC/DC
- Current - Maximum per Contact: 1.0A
- RoHS Compliance: Yes
- Halogen-Free: Yes
- Wire/Cable Type: Suitable for 28 AWG wire
- Packaging: Bag
Buy the Molex Series PicoBlade Pre-Crimped Lead: 2149211122
Purchase the Molex PicoBlade Connector Lead now to ensure secure, efficient connection solutions for your electronic projects. This 150mm, tin-plated, red pre-crimped lead supports 28 AWG wire and offers RoHS compliance, halogen-free design, and quick crimping for industry-grade reliability. Perfect for PCB assemblies, wire harnesses, and automation applications, this high-quality crimp lead enhances your workflow with durable, environmentally friendly components. Order online today for fast shipping and trusted performance.
Get Molex 2149211122 today—built for reliable electrical connections with quick crimping and eco-friendly RoHS compliance.
Frequently Asked Questions
Where can I buy MOLEX 2149211122?
You can click on the BUY or RFQ button to purchase 2149211122 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2149211122?
You can download the 2149211122 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2149211122?
MOLEX
