MOLEX 461120201 Power Receptacle Header
The EXTreme LPHPower Receptacle Header is a high-performance, 12.00mm pitch, vertical power connector featuring two gold-plated contacts for reliable power transmission. Designed for board-to-board applications, it boasts a high current capacity of 25A per contact, and a maximum voltage rating of 250V AC/DC. Made from high temperature thermoplastic and high-performance alloy, it offers durability up to 250 mating cycles. Suitable for various industrial and electronic applications, this RoHS-compliant connector combines robustness, ease of assembly, and excellent electrical performance in a compact form factor.
MOLEX 461120201 Power Receptacle Header Specifications:
- Pitch - Mating Interface: 12.00mm
- Pitch - Termination Interface: 12.00mm
- Number of Contacts: 2
- Color - Resin: Black
- Material - Metal: High Performance Alloy (HPA)
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Max Current per Contact: 25A
- Voltage - Maximum: 250V AC/DC
- Durability - Mating Cycles: 250
- Temperature Range - Operating: -40°C to +105°C
- Flammability: 94V-0
- Guide to Mating Part: None
- Lock to Mating Part: None
- Orientation: Vertical
- Packaging Type: Tray
- Surface Mount Compatible: No
- RoHS Compliance: Yes
- Halogen-Free: Yes
- Low-Halogen: Yes
- Certifications: UL, CSA
- Physical Weight: 1.84 g
Buy the Molex Series EXTreme LPHPower Power Receptacle Header: 461120201
Experience reliable power connectivity with the Molex Power Receptacle Header. Featuring a 12.00mm pitch, gold-plated contacts, and a robust high-performance alloy construction, it provides safe and efficient electrical connections for industrial, electronic, and board-to-board applications. With a maximum current capacity of 25A per contact and operating temperature up to 105°C, this RoHS-compliant connector ensures durability, safety, and high performance. Easy to install, it is ideal for designing durable electronic systems requiring secure power transmission.
Get Molex 461120201 today—built for durability and high-performance power connections in industrial and electronic applications.
Frequently Asked Questions
Where can I buy MOLEX 461120201?
You can click on the BUY or RFQ button to purchase 461120201 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 461120201?
You can download the 461120201 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 461120201?
MOLEX
