MOLEX 5054334071 Micro-Lock Plus Connector
The Micro-Lock Plus Vertical Header is a durable wire-to-board connector system with a 1.25mm pitch, dual-row design, and tin-bismuth plating. It supports 40 circuits, operates within -40°C to +105°C, and is rated for a maximum of 1.5A per contact at 50V AC/DC. Suitable for signal and wiring applications, it features a black polyamide resin body, vertical orientation, and PCB retention. Its reliable locking mechanism ensures stable connections, making it ideal for compact electronic assemblies requiring high durability and precise mating.
MOLEX 5054334071 Micro-Lock Plus Connector Specifications:
- Pitch - Mating Interface: 1.25mm
- Pitch - Termination Interface: 1.25mm
- Number of Circuits: 40
- Material - Resin: Polyamide
- Material - Metal: Brass
- Material - Plating - Mating: Tin-Bismuth
- Material - Plating - Termination: Tin-Bismuth
- Color: Black
- Net Weight: 1959.386 mg
- Durability: 30 mating cycles
- Operating Temperature Range: -40°C to +105°C
- Voltage - Max: 50V AC/DC
- Current - Max per contact: 1.5A
- Orientation: Vertical
- PCB Retention: Yes
- Surface Mount Compatibility: Yes
- Lock to Mating Part: Yes
- Guide to Mating Part: Yes
- Packaging: Embossed Tape on Reel
- UL Certification: E29179
Buy the Molex Series 505433 Micro-Lock Plus Wire-to-Board Connector: 5054334071
Discover the high-quality Molex Micro-Lock Plus Connector with a 1.25mm pitch, dual-row design, and tin-bismuth plating. This robust wire-to-board system supports 40 circuits at operating voltages up to 50V AC/DC and currents up to 1.5A per contact. Its vertical orientation, PCB retention, and lock-to-mating features ensure a secure, stable connection suitable for compact electronic assemblies. Ideal for signal applications, it meets UL certification and is compatible with surface mount technology, providing excellent durability for demanding environments.
Buy Molex 5054334071 now and experience unmatched reliability and performance with its durable, high-current, wire-to-board connection system.
