MOLEX 528080970 FFC/FPC Connector
The 1.00mm Pitch Easy-On™ FFC/FPC Connector is a surface mount, vertical, non-ZIF receptacle with 9 circuits designed for flexible flat cable applications. Made from high-temperature thermoplastic and featuring phosphor bronze contacts with tin-bismuth plating, it offers reliable electrical connections up to 0.5A and 125V AC/DC. This connector supports a temperature range of -20°C to +80°C, providing durability up to 10 mating cycles. Compatible with Molex Premo-Flex FFC connectors, it ensures secure PCB retention and quick surface mount assembly for reliable electronic device manufacturing.
MOLEX 528080970 FFC/FPC Connector Specifications:
- Pitch: 1.00mm
- Number of Circuits: 9
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin-Bismuth
- Material - Plating Termination: Tin-Bismuth
- Material - Resin: High Temperature Thermoplastic
- Temperature Range - Operating: -20°C to +80°C
- Current - Maximum per Contact: 0.5A
- Voltage - Maximum: 125V AC/DC
- Entry Angle: Vertical
- Durability (mating cycles max): 10
- Color - Resin: Natural
- Packaging Type: Embossed Tape on Reel
- Surface Mount Compatible: Yes
Buy the Buy Molex FFC-FPC Connector Part Number 0528080970 Online
Enhance your electronic projects with the Molex FFC/FPC connector featuring a 1.00mm pitch and 9 circuits, designed for surface mount applications. Its durable high-temperature thermoplastic body and phosphor bronze contacts with tin-bismuth plating guarantee reliable electrical connections up to 0.5A and 125V AC/DC. Ideal for flexible flat cable use, it supports a temperature range of -20°C to +80°C, ensuring stable performance across various environments. Quick surface mount assembly makes it suitable for demanding manufacturing processes and durable device assembly.
Order your Molex Series52808 FFC-FPC Connector 0528080970 today and ensure a reliable, high-quality connection for your flexible cable applications.
Frequently Asked Questions
Where can I buy MOLEX 528080970?
You can click on the BUY or RFQ button to purchase 528080970 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 528080970?
You can download the 528080970 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 528080970?
MOLEX
