MULTICOMP PRO 2211R02GSMCR 2.54mm pitch header with cap
This high-quality 2.54mm pitch header with cap features a right angle, SMD mounting style, and single row configuration, suitable for compact electronic modules. Made from high-temp nylon with gold-plated copper contacts, it supports a current of 3A and voltage of 250V AC/DC. The header exhibits low contact resistance of 20mΩ max and insulation resistance of 1000MΩ. It withstands a voltage of 600V AC for one minute, operates within -40°C to +105°C, and complies with RoHS standards, ensuring durability and excellent electrical performance in space-constrained applications.
MULTICOMP PRO 2211R02GSMCR 2.54mm pitch header with cap Specifications:
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: 20mΩ Max
- Insulation Resistance: 1000MΩ Min
- Withstanding Voltage: 600V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- Materials and Finish: Copper Alloy contacts, Gold plated, High Temp Plastic (Nylon 6T UL94V-0)
- Insulator Colour: Ivory
- Contact Material: Copper Alloy
- Dimensions: 2.54mm pitch, 1 Row, various positions from 2 to 24, SMD style
Buy the Buy Multicomp 2.54mm Pitch Header Part Number 2211R-02G-SM-CR Online
Secure your electronic projects with the Multicomp 2.54mm pitch header featuring a right-angle SMD design and gold-plated copper contacts. This high-quality connector supports 3A current and 250V voltage ratings, ensuring efficient, reliable connections. Made from high-temp nylon with RoHS compliance, the headers are perfect for space-constrained applications requiring durability and excellent electrical performance. Easy to install, these headers are an essential component for electronic assemblies needing precise and secure connections in compact spaces.
Buy Multicomp 2211R-02G-SM-CR now and experience reliable, space-saving electronic connections with high-temp耐 Plastic and gold-plated contacts.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 2211R02GSMCR?
You can click on the BUY or RFQ button to purchase 2211R02GSMCR from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 2211R02GSMCR?
You can download the 2211R02GSMCR datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 2211R02GSMCR?
MULTICOMP PRO
