MULTICOMP PRO 2211SM14GB1TB SMD Header Connector
This 2.54mm pitch vertical SMD header features a 1-row, staggered configuration available in various POS sizes, ideal for tight PCB layouts. It is constructed with high-temperature nylon UL94V-0 insulator, copper alloy contacts, and gold plating to ensure excellent current capacity and corrosion resistance. With a voltage rating of 250V AC/DC and a current rating of 3A, it supports reliable connections for electronic assemblies. Designed for durability, the header maintains performance within an operating temperature range of -40°C to +105°C, suitable for various industrial and consumer applications.
MULTICOMP PRO 2211SM14GB1TB SMD Header Connector Specifications:
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: 20mΩ Max.
- Insulation Resistance: 1000MΩ Min.
- Withstanding Voltage: 600V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- Materials and Finish: Copper Alloy contact, Gold Plated, High Temp. Plastic (Nylon 6T UL94V-0)
- Insulator Colour: Ivory
- Dimensions: Pitch 2.54mm, Staggered, Various POS sizes
- Flammability: UL 94V-0
- RoHS Compliant: Yes
Buy the Multicomp Series 2.54mm Vertical SMD Header: 2211SM14GB1TB
Purchase the high-quality 2.54mm vertical SMD header with 1-row configuration in multiple POS sizes online. Designed with durable materials including gold-plated copper contacts and high-temperature nylon insulator, this connector ensures reliable electrical connections in PCB assemblies. Rated for 3A and 250V, it withstands temperatures from -40°C to +105°C, making it suitable for various industrial, commercial, and consumer electronic applications. Easy to install and RoHS compliant, ensuring safety and environmental standards are met. Order now for fast delivery and reliable performance.
Get Multicomp Series 2.54mm Vertical SMD Header 2211SM14GB1TB today—built for reliable connections and long-lasting durability.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 2211SM14GB1TB?
You can click on the BUY or RFQ button to purchase 2211SM14GB1TB from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 2211SM14GB1TB?
You can download the 2211SM14GB1TB datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 2211SM14GB1TB?
MULTICOMP PRO
