MULTICOMP PRO 2212S10SG85 PCB Socket Single Row
The MULTICOMP PRO 2212S-10SG-85 is a 10-way, 2.54mm pitch PCB socket designed for secure and reliable connections in electronic circuits. Constructed with a PBT insulator and copper alloy contacts featuring selective gold plating, this connector offers excellent electrical performance and durability. It is suitable for a wide range of applications including industrial automation, consumer electronics, and telecommunications equipment. The socket's straight configuration simplifies integration into PCB designs, ensuring efficient and space-saving assembly.
MULTICOMP PRO 2212S10SG85 PCB Socket Single Row Specifications:
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Max. Contact Resistance: 20mΩ
- Min. Insulation Resistance: 1,000 MΩ
- Withstanding Voltage: 600V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- Insulator Material: PBT
- Contact Material: Copper alloy
- Contact Finish: Selective gold plated
- General Tolerance: 0.X=±0.2, .XX=±0.15
- Number of Contacts: 10
- A (mm): 25.9
- B (mm): 2.54, 5.08, 7.62, 10.16, 12.7, 17.78, 22.86
